Grey Catalyst Bed Suport Media Alumina Oxide Ceramic Balls In Reactor
Grey Catalyst Bed Suport Media Alumina Oxide Ceramic Balls In Reactor
Grey Catalyst Bed Suport Media Alumina Oxide Ceramic Balls In Reactor
Grey Catalyst Bed Suport Media Alumina Oxide Ceramic Balls In Reactor
Specifications
Brand Name :
NKCHEM
Model Number :
ICB-002
Certification :
ISO
Place of Origin :
China
MOQ :
1000kg
Price :
USD0.4-USD1
Payment Terms :
Western Union, T/T, L/C,PAYPAL, Credit card
Supply Ability :
200 TON per Month
Delivery Time :
3-4 work day
Packaging Details :
woven bag
Name :
Alumina oxide Ceramic Ball
Al2O3 :
17%
Shape :
Ball
Size :
3mm, 6mm, 8mm, 10mm, 13mm, 16mm, 20mm or customized
Color :
White, grey
Application :
covering and support material for catalyst and packing
Other names :
inert ceramic ball, alumina ceramic ball
Material :
Ceramic
Description

Grey Catalyst Bed Suport Media Alumina Oxide Ceramic balls In Reactor

1．Inert Ceramic Ball

Inert ceramic alumina ball has stable chemical features and a low rate of water absorption, resistant to high temperature and high pressure. It is also resistant to the corrosion of acid, alkali and some other organic solvents. They can stand the rapid changes in temperature during the manufacturing process.

Inert ceramic alumina ball Physical Prosperities:

Product name

Item

 Low Alumina Ball Middle Alumina Ball High Alumina Ball
Al2O3 17-35% 60-75% 80-95%
Al2O3 +SiO2(%) ≥92% ≥92% ≥95%
Fe2O3(%) 1% 1% 0.5%
CaO (%) 1.5% 2.1% 2.9%
MgO (%) 2.5% 1.3% 0.5%
K2O+Na2O(%) 4.0% 4.0% 4.0%
TiO2 (%) 0.5% 0.1% 0.1%
Water absorption 3%
Acid resistance 98%
Alkali resistance 80% 85% 90%
Operation Temperature (°C) 980 1180 1580
Spalling Resistance(°C) 300 500 700
Gravity(g/cm3) 2.3-2.4 2.6 3.5
Mohs hardness Max 6.5 7.0 7.0

Compressive
Strength
KN/Pellet

 Ø6 0.4 0.5 0.6
Ø13 1.2 1.6 1.7
Ø20 1.8 2.0 2.3
Ø25 2.5 2.9 3.2
Ø38 4.0 4.5 5.0
Ø50 8.0 8.5 11


Specification:

Dia(Φ) 3 6 8 10 13 16 20 25 30 38 50 65 75
Allowable deviation ±1.0 ±1.5 ±2.0 ±3.0

Grey Catalyst Bed Suport Media Alumina Oxide Ceramic Balls In Reactor

Grey Catalyst Bed Suport Media Alumina Oxide Ceramic Balls In Reactor
