Video/Audio Input

Video Compression: H.264

Video Input: 4-channel

OSD: Text, Time/date, car ID,GPS info

Audio Compression: G.726

Audio Input: 4-ch

Audio Input Interface: Aviation Interface (linear electrical level, 1 kΩ)

Two-way Audio: 1 Aviation Interface (Linear electrical level, 1KΩ)

Video/Audio Output

Live View Resolution: 4CIF (PAL: 704x576, NTSC: 704x480)

VGA Output: 1-ch, resolution: 800x600/60Hz, 800x600/75Hz, 1024x768/60Hz

Recording resolution: D1/CIF/QCIF,up to 2ch D1+2ch CIF

Video output: 1-ch, Aviation Interface

Frame Rate: 25(P)/30(N) fps

Video Bit Rate: 32Kbps~2048Kbps, or user-defined (Max.3Mbps)

Stream Type: Video/Video&Audio

Audio Output: 1-ch RCA(Linear electrical level, 600Ω)

Audio Bit Rate: 16kbps

HDD/SD card

Interface Type: 1 pluggable SATA interfaces

Capacity: Up to 2TB capacity

Technical Patent: Hard disk vibration-proof and bracing technology

SD card: 1 SD card support up to 32G(for mirror)

Alarm

Alarm input/output : 6ch switch-value input/1ch switch-value output

Alarm record: Pre-record 15seconds,post record(30s~30min)

Alarm for remaining HDD space, Support for remaining HDD space alarm

Function alarm: GPS speeding, acceleration, Motion Detection

Wireless Transmission

Embedded 3G wireless transmission module, WCDMA, CDMA2000, TD-SCDMA system for selection;Compatible with GPRS, EDGE;Embedded Wi-Fi module;

Interface

Network Interface: 1 RJ45 10M/100M adaptive Ethernet Interface

3G(option): Built-in WCDMA/CDMA2000 module

USB Interface: 1 USB 2.0 interface

Serial Interface: 1 RS-232 interface; 1 RS-485 interface

Alarm Input: 6-ch switch-value signal

Alarm Output: 1-ch switch-value signal

Remote Control: IR Remote Control

GPS(option): Built-in GPS Module,

G-sensor :Built-in

General

Power Input: 6~36V DC adaptive

Power Output: 12V/2A DC, 5V/0.5A DC output

Power Off Delay: Patent UPS technology, can working 3~5 seconds after

power shut down suddenly

Power On/Off:

1. ACC power on/off

2. HDD lock power on/off

3. Delay power on/off

4. Scheduled power on/off

Consumption: ≤10W (working); <0.5 W(standby)

Working Temperature: -25°C~+60°C(-13°F~140°F)

Working Humidity: 10%~95%

Dimensions: 19.8cm (L) * 15.8cm (W) * 6.5cm (H)

Weight: 3500g(7.7lbs)

Note: The specs are subject to change without prior notice.
