Specifications
Brand Name :
Sacon
Model Number :
SA-VJ10
Certification :
ISO9001, CE
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C,T/T,Western Union,Paypal
Supply Ability :
1000 sets per year
Delivery Time :
6 working weeks after receive payment
Packaging Details :
Outer box: universal wooden box ; Antenna: Beautify the roof luggage (internal antenna)
Product Name :
Convoy IED Bomb Jammer
Output Power :
560W
Jamming Range :
100 ~ 200 Meters @Depends On The Strength Signal In Given Area
Built-in Battery :
Continuous Use For More Than 3 Hours
Dimension :
1280×800×291 (mm)
Weight :
120kg
Description
Vehicle Convoy Bomb Jammer Block 560 Watt 10 Channels Frequency 20Mhz To 6GHz
Product Overview

The SA-VJ10 vehicle-mounted mobile phone signal sealing and control system is designed to block and control key communication bands within the 20MHz to 6000MHz frequency range. This system prevents terrorists and unauthorized entities from using wireless communication devices to detonate RCIEDs (Radio-Controlled Improvised Explosive Devices) and conduct terrorist attacks.

As a radio signal jamming system mounted on vehicle roofs, it provides basic protection for single vehicles in transit against IED threats. The system features even power distribution of internal RF jamming telemetry and optimal cooling for desert climate operations.

Key Features
  • Easy installation with no vehicle modifications required
  • Automatic fault protection: system automatically closes faulty modules during overheating, low power output, or high standing wave conditions
  • Modular construction for easy maintenance and upgrades
  • Simple operation with large interference radius
  • Comprehensive system design meeting operational requirements
  • Individual frequency and power switching capability
  • Wired control mode operation
  • Power amplifier protection design ensuring device reliability
Technical Specifications
Channel Frequency Range Application Output Power
CH120~200MHzWireless Toys, FM Radio100W
CH2200~500MHzWalkie-talkie (VHF,UHF), Remote Control, Car alarm, Drone100W
CH3500-1000MHzCDMA, GSM, LTE700, LTE800100W
CH41000~1500MHzDrone, GPS100W
CH51500~2000MHzDCS, PCS, GPS, AWS100W
CH62000~2500MHz3G, WIFI100W
CH7851~894 MHzCellular CDMA100W
CH8902-960MHzCellular GSM, E-GSM, Drone100W
CH91805~1990MHzCellular DCS, PCS100W
CH102110~2170MHzCellular WCDMA100W
CH112400-2500MHzWIFI, Drone50W
CH122500-3000MHzMMDS, LTE2500, LTE260050W
CH133000-4000MHzFuture Band (Reserve)10W
CH144000-5000MHzFuture Band (Reserve)10W
CH155000-6000MHzWiFi, WLAN, Drone15W

Power Supply: AC110-240V, DC 28V

Output Power: 1135W

Jamming Radius: 50-800M (depending on environment signal strength)

Power Consumption: 3400W

Weight: 75Kg

External Omni Antennas Size (L×H×W): 640×540×550mm

Humidity: 5%-95%

Working Temperature: -10°C to +55°C

Applications
  • Accompanying Type Control: Sealing and controlling mobile phone signals during vehicle transit
  • Parking Type Control: Blocking mobile communication signals in emergency locations during important public events to prevent RCIED terrorist attacks
  • Information Security: Preventing leakage of important information by blocking local area communications
Product Images
560W 10 Channels Vehicle Convoy Bomb Jammer with 20MHz to 6GHz Frequency Range for IED Protection 560W 10 Channels Vehicle Convoy Bomb Jammer with 20MHz to 6GHz Frequency Range for IED Protection
