Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Specifications
Brand Name :
SPR-ing
Model Number :
SP025
Place of Origin :
Shenzhen
MOQ :
1 piece
Price :
200~800 USD
Payment Terms :
L/C,T/T
Supply Ability :
1000/month
Delivery Time :
1~3 weeks
Packaging Details :
Carton
Insulation Resistance :
200MΩ/250V/DC
Shell Material :
303 stainless steel
Product Name :
Conpact Size Slip Ring High Speed Rotary Ring Long Life Span Joint Ring
Wire Specification :
AF200-0.05mm²
Rated Current :
1 A
Operating Temperature :
-40℃ ~ 80℃
Contact Material :
Gold-gold
Application Areas :
Used for high-speed testing platform strain gauge signals, thermocouple signals, etc.
Description
Multi-media Slip Rings with HDMI and USB Interfaces
Compact rotary joint ring designed for smooth data transmission in rotating digital signage and interactive kiosks, featuring integrated HDMI and USB interfaces.
Product Overview
The Mini Slip Ring is a compact and lightweight rotary electrical connector designed for high-speed testing platforms and other precision applications. With a weight under 60g (excluding wires), it provides reliable signal transmission while maintaining a minimal footprint.
Key Features
  • Product Name: Mini Slip Ring
  • Working Life: 10 Million RPM
  • High insulation resistance: 200MΩ at 250V DC
  • Wire Specification: AF200-0.05mm²
  • Compact design: Weight <60g (excluding wires)
  • Rated for speeds from 0 to 300 RPM
Technical Specifications
Parameter Specification
Contact Material Gold-gold
Rated Voltage 0-100VDC
Dielectric Strength >200VAC/50Hz/60s
Shell Material 303 stainless steel
Operating Humidity ≤80%
Applications
The SPR-ing SP025 Mini Slip Ring is ideal for:
  • Robotics and automation systems
  • CCTV and surveillance equipment
  • Medical imaging and diagnostic devices
  • Industrial automation and motion control
  • High-speed testing platforms
Product Images
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Multi Media HDMI USB Mini Slip Ring Rotary Connector for Digital Signage Interactive Kiosk Systems
Support & Services
Our technical support team provides comprehensive assistance with installation, troubleshooting, and maintenance. We offer training sessions and detailed product documentation to ensure optimal performance.
Shipping Information
  • Package Includes: Mini Slip Ring, User Manual
  • Shipping Method: Standard Shipping
  • Delivery Time: 5-7 business days
  • Shipping Cost: $5.99
Frequently Asked Questions
Q: What is the brand name of the Mini Slip Ring product?
A: The brand name is SPR-ing.
Q: What is the model number?
A: The model number is SP025.
Q: Where is the product manufactured?
A: The product is manufactured in Jiujiang.
