Ultra Miniature Capsule Slip Ring 12 Circuit 2A Micro Rotary Connector for Drone Gimbal Camera
Ultra Miniature Capsule Slip Ring 12 Circuit 2A Micro Rotary Connector for Drone Gimbal Camera
Ultra Miniature Capsule Slip Ring 12 Circuit 2A Micro Rotary Connector for Drone Gimbal Camera
Ultra Miniature Capsule Slip Ring 12 Circuit 2A Micro Rotary Connector for Drone Gimbal Camera
Ultra Miniature Capsule Slip Ring 12 Circuit 2A Micro Rotary Connector for Drone Gimbal Camera
Ultra Miniature Capsule Slip Ring 12 Circuit 2A Micro Rotary Connector for Drone Gimbal Camera
Specifications
Operating Temperature :
-40°C to +80°C
Brand Name :
WNRLN
Rated Voltage :
240V AC/DC
Housing Material :
Engineering Plastic (POM)
Certification :
ISO 9001:2015, CE, RoHS
Supply Ability :
5000 Pieces per Month
Contact Material :
Gold to Gold
Place of Origin :
Guangdong, China
Delivery Time :
3-5 working days for stock, 15-25 days for production
Operating Speed :
0-300 rpm
Number of Circuits :
12
Insulation Resistance :
≥500MΩ at 500VDC
MOQ :
1 Piece
Packaging Details :
WNRLN branded box with anti-static foam insert, export-grade corrugated carton
Rated Current :
2A per circuit
Protection Grade :
IP54
Price :
USD 25-100 / Piece
Payment Terms :
T/T, L/C, PayPal, Western Union
Lead Wire Length :
150mm (customizable)
Model Number :
MSR-12C-2A-CAP
Outer Diameter :
15.5mm
Dielectric Strength :
≥500V AC at 50Hz
Description

Ultra Miniature Capsule Slip Ring 12 Circuits 2A – Micro Rotary Connector

Product Overview

The WNRLN MSR-12C-2A-CAP Ultra Miniature Capsule Slip Ring pushes miniaturization to the extreme with a 15.5mm outer diameter while still providing 12 independent 2A circuits. Designed specifically for drone gimbal cameras, this capsule-type slip ring offers gold-gold contact reliability in the smallest possible package for weight-sensitive aerial applications.

Key Features

  • Ultra Compact Capsule Design: 15.5mm diameter cylindrical form factor for extreme space constraints.
  • Gold-Gold Contact Technology: Micro gold-plated contacts deliver consistent FPV video signal quality.
  • Micro Drone Gimbal Application: Optimized for lightweight drone camera stabilization systems.
  • Minimal Weight: Under 30g total weight minimizes impact on drone flight performance.

Technical Specifications

ParameterValue
Number of Circuits12
Rated Current2A per circuit
Rated Voltage240V AC/DC
Dielectric Strength≥500V AC at 50Hz
Contact MaterialGold to Gold
Housing MaterialEngineering Plastic (POM)
Operating Speed0-300 rpm
Protection GradeIP54
Lead Wire Length150mm (customizable)
Outer Diameter15.5mm

Applications

  • Drone Gimbals: 3-axis camera stabilization with continuous 360° rotation.
  • Wearable Cameras: Compact rotating camera modules.
  • Micro Robotics: Miniature joint actuators in small robotic systems.

Quality Assurance

  • ISO 9001:2015 certified facility
  • CE and RoHS compliant
  • 100% continuity testing under rotation
