Burglary Prevention 3 Phase Current Transformer , Metal Outer Case DC Current Transformer
Burglary Prevention 3 Phase Current Transformer , Metal Outer Case DC Current Transformer
Specifications
Brand Name :
WSD
Model Number :
WSD-725D
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200000/day
Delivery Time :
14-21days
Packaging Details :
Cartons / Pallets
Max current :
40-60A
Primary current :
5-10A
Secondary current :
2-10mA
Accuracy class :
0.1
Anti-magnetic :
Available
DC immunity :
Available
Description

3 Phase current transformer prevention of burglary DCT with metal outer case current transformer

Suitable for high precision, small phase error requirments of three-phase electric energy meters
More space in the meter can be saved with combined current transformer
Linear output current, high precision
Encapsulated with epoxy resion,with high insulation ability
It accords with IEC60044-1 0.05 class, 0.1 class, 0.2 class
Parameters:

Rated primary current Max primary current Rated secondary current Turn ratio Accuracy class DC component Shileding Load resistance
I p(A) I max(A) I s(mA) N (%) (%) (T) Rb
5 60 2 1:2500 0.1/0.2 ±3% 300mT 5Ω,10Ω,20Ω
5 60 2.5 1:2000 0.05/0.1/0.2 　
10 60 4 1:2500 0.1/0.2 ±3%
10 60 5 1:2000 0.05/0.1/0.2 　
10 60 10 1:1000 0.1/0.2 　
5 80 2 1:2500 0.05/0.1/0.2 ±3% unavailable
10 80 4 1:2500 0.05/0.1/0.2 ±3%
10 100 4 1:2500 0.1/0.2 ±3%
20 100 8 1:2500 0.1/0.2 ±4%
　 　 　 　 　 　
Working temperature −40℃~ 85℃
Isolation voltage 4000Vrms, 1 Min, No breakdown, No arcing
Insulation resistance ≥1000MΩ
Operating temperature 50Hz~60Hz

Dimension:
Burglary Prevention 3 Phase Current Transformer , Metal Outer Case DC Current Transformer
