Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
Specifications
Brand Name :
Minfeng
Model Number :
bbtrz
Certification :
ISO,CE,IEC,TUV,KEMA
Place of Origin :
Hebei, China
MOQ :
100
Price :
0.1-5
Payment Terms :
L/C,T/T
Supply Ability :
100KM/Week
Delivery Time :
10 Days
Origin :
China
Jacket Color :
Orange or optional
Size :
1.5-800mm2
Hs Code :
8544492100
Outerdiameter :
Varies by size
Sheathmaterial :
LSZH (Low Smoke Zero Halogen)
Color :
Orange
Flameretardant :
Yes
Description
Bbtrz Flexible Mineral Insulated Fireproof High Temperature Resistant Power Cable
Product Specifications
Rated Voltage 0.6-1kV
Size Customization
Conductor Material Copper
Insulation Material XLPE
Working Temperature 70°C, 90°C
Jacket PVC
Application Power Distribution, Construction, Home Appliance, Photovoltaic Power, Industrial, Mining, Power Station, Building, Other
Rated Current Customization
Type Low Voltage
Place of Origin Hebei, China
Model Number Customization
Brand Name Minfeng
Color Customer's Requirement
Service ODM OEM Accepted
Product Structure Features
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
  • Excellent High Temperature Resistance: XLPE insulation transforms polyethylene molecules into a three-dimensional network structure, enabling long-term operation at 90°C with a lifespan up to 40 years
  • Superior Insulation Performance: Maintains cross-linked polyethylene insulation properties with enhanced insulation resistance
  • High Mechanical Properties: Improved hardness, stiffness, wear resistance, and impact resistance
  • Chemical Resistance: Strong resistance to acids, alkalis, and oils
  • Environmental Protection: Combustion produces only water and carbon dioxide, meeting fire safety requirements with low environmental impact
  • Temperature Ratings: Maximum conductor temperature of 90°C during normal operation; up to 250°C during short circuit (maximum 5 seconds duration)
Product Introduction
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable

Insulated PVC/XLPE sheathed power cable designed for power transmission and distribution systems with rated voltages of 0.6/1, 1.8/3, 3.6/6, 6/10, 8.7/10, 8.7/15, 12/20, 21/35, 26/35KV.

Cable Types & Applications
  • YJV, YJLV: XLPE insulated, PVC sheathed power cables suitable for indoors, tunnels, pipes, and buried in soil (not subject to mechanical force)
  • YJV22, YJLV22: XLPE insulated, steel tape armored PVC sheathed power cables suitable for indoor, tunnel, pipe penetration, and buried in soil
  • YJV32, 42, YJLV32, 42: XLPE insulated, steel wire armored PVC sheathed power cables suitable for shafts, water applications, areas with drop, and environments requiring external force resistance
Technical Specifications
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
  • Normal Operation Temperature: Maximum conductor temperature of 70°C for PVC insulation and 90°C for XLPE insulation
  • Short Circuit Temperature: PVC insulation - 160°C for conductor cross section ≤300mm², 140°C for conductor cross section >300mm²; XLPE insulation at 250°C
  • Installation Requirements: Ambient temperature not less than 0°C during cable laying
  • Minimum Bending Radius: Single core cable: unarmored 20D, armored 15D; Multi-core cable: unarmored 15D, armored 12D (where D = actual outer diameter of cable)
  • Cable Breaking Force: Aluminum core cable: 40*S (N); Copper core cable: 70*S (N)
Packing & Delivery
Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable Flexible Fireproof Mineral Insulated Cable XLPE Insulated Flame Retardant Power Cable
