Axclight-H LT 12KV/24KV Medium Voltage Cable with Aluminum Conductor and PE LLD Outer Sheath
Axclight-H LT 12KV/24KV Medium Voltage Cable with Aluminum Conductor and PE LLD Outer Sheath
Axclight-H LT 12KV/24KV Medium Voltage Cable with Aluminum Conductor and PE LLD Outer Sheath
Axclight-H LT 12KV/24KV Medium Voltage Cable with Aluminum Conductor and PE LLD Outer Sheath
Specifications
MOQ :
100m
Delivery Time :
5-8 Days
Cable Standard :
SS 424 14 16
Model Number :
Axclight-H LT
Cable Mark :
Ink printing or embossing
Payment Terms :
L/C,T/T
Price :
0.1-5
Corporation :
Minfeng cable group
Supply Ability :
100KM/Week
Brand Name :
Minfeng
Rated Voltage :
12KV/24KV
Packaging Details :
Wooden Drum
Certification :
ISO,CE,IEC,TUV,KEMA
Temperature Range :
-20℃~+90℃
Place of Origin :
Hebei, China
Insulation material :
XLPE (Cross-Linked Polyethylene)
Description
Axclight-H LT 12 KV 24 KV Cable Aluminum Conductor XLPE Insulation PE LLD Outer Sheath
Product Overview
Rated Voltage 12KV/24KV
Size 50-95mm²
Conductor Material Aluminum
Insulation Material XLPE
Working Temperature 90°C
Jacket PE LLD
Application Industrial
Type Medium Voltage
Product Description
Axclight-H LT 12 KV 24 KV Cable Aluminum Conductor XLPE Insulation PE LLD Outer Sheath
Axclight-H LT is a halogen-free, XLPE-insulated, copper wire screened and PE-sheathed three-core medium voltage cable with a supporting strand and circular aluminum conductors. The cable is designed according to HD 620.S2 2010 10M. The conductors are longitudinally water blocked by swellable powder and meet the requirements for SS EN 60228 class 2. The sheath is marked with type/manufacturer/year+month/metre marking. Axclight-H LT is not flame retardant. Joint and cable terminations are standard materials from accessory manufacturers.
Product Characteristics
  • Construction: Aluminum conductor, round stranded shape, XLPE insulation, PE LLD outer sheath
  • Color: Black
  • Halogen Free: Yes
  • Conductor Flexibility: Class 2
  • Number of Cores: 3
  • Minimum Insulation Thickness: 2.96 mm
  • Rated Voltage Uo/U (Um): 7 / 12 kV
  • Minimum Installation Temperature: -20 °C
  • Maximum Operating Temperature: 90 °C
  • Short-circuit Max. Conductor Temperature: 250 °C
  • Rip Cord: Yes
  • U.V Resistance: Good
Standards & Specifications
Product Standards: HD 620
National Standard: SS 424 14 16
Name Conductor Cross-section [mm²] Screen Section [mm²] Nominal Outer Diameter [mm]
Axclight-H LT 12 kV
Axclight-H LT 12 kV 3X50/16 50 42 180
Axclight-H LT 12 kV 3X95/25 95 51 251
Axclight-H LT 24 kV
Axclight-H LT 24 kV 3X50/16 50 51 235
Axclight-H LT 24 kV 3X95/25 95 59 313
