High Sensitivity Nuclear Radiation Detector with Real-Time Monitoring and Compact Design for Medical Applications
High Sensitivity Nuclear Radiation Detector with Real-Time Monitoring and Compact Design for Medical Applications
High Sensitivity Nuclear Radiation Detector with Real-Time Monitoring and Compact Design for Medical Applications
High Sensitivity Nuclear Radiation Detector with Real-Time Monitoring and Compact Design for Medical Applications
High Sensitivity Nuclear Radiation Detector with Real-Time Monitoring and Compact Design for Medical Applications
High Sensitivity Nuclear Radiation Detector with Real-Time Monitoring and Compact Design for Medical Applications
Specifications
Brand Name :
Airppb
Model Number :
MR-NUI
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
D/P,T/T
Supply Ability :
100
Delivery Time :
5-8work days
Packaging Details :
Outer packing: carton inner lining with wooden case reinforcement.
Weight And Size :
About 350*250*245(mm), About 9.8Kg
Craft :
Geiger Counter
Intrinsic Error :
<±10%
Device Weight :
≤8 kg
Size :
120*65*25mm
Detectable Items :
α, β, X, γ
Operating Temperature :
-20°C To 50°C
Dimensions :
150mm x 70mm x 30mm
Warranty :
1 Year
Description
Product Data Sheet

Product: High Sensitivity Personal Dosimeter

Model: MR-NUI100

Product Overview

The MR-NUI100 provides precise radiation dose monitoring for medical applications.

Key Features:
  • CsI crystal + SiPM detector — high sensitivity design
  • Real-time dose rate measurement
  • Simultaneous cumulative dose recording
  • Environmental background radiation response
  • Audible, visual, LCD display alarms
  • Continuously adjustable alarm threshold
  • Built-in lithium battery power
  • Compact 50g lightweight design
Application Scenarios:
  • Nuclear Medicine Departments
  • Radiology Staff Monitoring
  • Radiotherapy Patient Protection
  • Medical Radiation Safety
  • Occupational Dose Tracking
  • Hospital Radiation Control
  • Medical Imaging Protection
  • Radiation Therapy Monitoring
  • Medical Staff Safety
  • Clinical Radiation Management
Technical Specifications
Item Parameter
Detector Type CsI Crystal + SiPM Detector
Measured Radiation Type Gamma Rays (γ-rays)
Dose Rate Measurement Range 0.1 μSv/h ~ 100 mSv/h
Cumulative Dose Measurement Range 0.1 μSv ~ 10 Sv
Sensitivity (¹³⁷Cs)2 cps/μSv/h
Intrinsic Error <10%
Energy Range 48 keV ~ 3 MeV
Response Time <1 s
Alarm Threshold 0.5 μSv/h ~ 50 mSv/h continuously adjustable
Alarm Functions Dose rate exceed threshold, battery undervoltage alarm
Alarm Modes Audible and visual alarm, LCD display alarm
Memory 8M, capable of storing approximately 30 days of data
Communication Method Bluetooth
Power Supply Built-in lithium battery
Operating Environment -10°C ~ +50°C, ≤95% RH
Dimensions 61.5 mm × 33 mm × 12.5 mm
Weight 50 g

High Sensitivity Nuclear Radiation Detector with Real-Time Monitoring and Compact Design for Medical ApplicationsHigh Sensitivity Nuclear Radiation Detector with Real-Time Monitoring and Compact Design for Medical Applications

Key Advantages:
  • High Sensitivity — CsI + SiPM advanced detection
  • Real-Time Monitoring — Instant dose rate measurement
  • Wide Range — 0.1 μSv/h to 100 mSv/h coverage
  • Compact Design — 50g lightweight personal device
  • Long Storage — 30 days data recording capability
  • Medical Optimized — Healthcare radiation safety
