Portable γ Camera with 50–1500 keV Imaging Range, ≤9% Energy Resolution, and ≤8 kg Lightweight Design for Emergency Response and Environmental Monitoring
Portable γ Camera with 50–1500 keV Imaging Range, ≤9% Energy Resolution, and ≤8 kg Lightweight Design for Emergency Response and Environmental Monitoring
Portable γ Camera with 50–1500 keV Imaging Range, ≤9% Energy Resolution, and ≤8 kg Lightweight Design for Emergency Response and Environmental Monitoring
Portable γ Camera with 50–1500 keV Imaging Range, ≤9% Energy Resolution, and ≤8 kg Lightweight Design for Emergency Response and Environmental Monitoring
Specifications
Brand Name :
Airppb
Model Number :
MR-MUC
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
$195000
Payment Terms :
D/P,T/T
Supply Ability :
100
Delivery Time :
5-8
Packaging Details :
Outer packing: carton inner lining with wooden case reinforcement.
Imaging Energy Range :
50–1500 keV
Energy Resolution :
≤9% (for Cs-137 source)
Imaging Field of View :
≥40°
Angular Resolution :
≤2.5°
Imaging Positioning Sensitivity :
Capable of imaging and positioning a Cs-137 test source with a dose rate of 30 nGy/h at the detector under natural background within 180 s
Device Weight :
≤8 kg
Description
Portable γ Camera - Model MR-MUC
Product Introduction
This advanced portable γ camera utilizes the coded-aperture radiation imaging principle. It employs a scintillation crystal array and SiPM array, combined with proprietary image reconstruction and fusion algorithms. Equipped with a laser rangefinder, it enables fast, real-time imaging of radiation hotspots while intuitively displaying their position and approximate shape.
Main Features
  • Real-time radiation imaging capability
  • Wide field of view with high position resolution
  • Advanced nuclide identification
  • Proprietary image reconstruction and fusion algorithms
  • Adaptable to multi-purpose and complex environmental scenarios
Technical Specifications
Parameter Details
Imaging Energy Range 50–1500 keV
Energy Resolution ≤9% (for Cs-137 source)
Imaging Field of View ≥40°
Angular Resolution ≤2.5°
Imaging Positioning Sensitivity Capable of imaging and positioning a Cs-137 test source with a dose rate of 30 nGy/h at the detector under natural background within 180 s
Device Weight ≤8 kg
Application Fields
  • Customs & Airport Inspection
  • Security & Critical Infrastructure Protection
  • Radiological Medicine
  • Environmental Radioactivity Monitoring
  • Nuclear Power Operation, Maintenance & Emergency Disposal
Core Advantages
  • Imaging range 50–1500 keV, covering mainstream radiation source detection requirements
  • Energy resolution ≤9% for Cs-137 source, enabling high-definition imaging and accurate identification
  • Fast positioning of low-dose radiation sources within 180 seconds, significantly improving emergency detection efficiency
  • Lightweight body ≤8 kg, portable and easy to operate, designed for single-person carry and operation
Product Configuration
  • Packing List: 1 copy
  • Operation Manual: 1 copy
  • Certificate of Conformity: 1 copy
  • Power Cable: 1 piece
