Specifications
Brand Name :
Airppb
Model Number :
MR-NUI500
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
D/P,T/T
Supply Ability :
100
Delivery Time :
5-8work days
Packaging Details :
Outer packing: carton inner lining with wooden case reinforcement.
Detectable Items :
x, gamma and hard beta rays
Relative Inherent Error :
±15%
Installation Type :
Fixed And Mobile
Measurement Range :
0.01 μSv/h to 10 Sv/h
Remote Control System :
Yes
Cross Talk :
β→α < 0.1%; α→β < 2%
Detection Window Area :
75 cm²
Detection Type :
Alpha, Beta, Gamma, Neutron
Relative Innate Error :
≤ ± 10 % (137 CS 1 MSv/h)
Energy Response :
25KeV ~ 3MeV
Dimensions :
150 mm x 70 mm x 40 mm
Description
Product Data Sheet

Product: Portable Personal Gamma Survey Device

Model: MR-NUI500

Product Overview

The MR-NUI500 provides precise gamma radiation monitoring for environmental applications.

Key Features:
  • Dual detector system — scintillator and semiconductor
  • High sensitivity 400 cps/(μSv/h)
  • Wide dose rate range coverage
  • Three measurement modes available
  • Configurable alarm thresholds
  • Audible, visual, vibration alarms
  • Compact 280g portable design
  • IP65 weather-resistant rating
Application Scenarios:
  • Environmental Radiation Monitoring
  • Nuclear Facility Surveillance
  • Background Radiation Assessment
  • Environmental Impact Studies
  • Nuclear Emergency Response
  • Radioactive Pollution Detection
  • Environmental Radiation Mapping
  • Nuclear Safety Inspection
  • Radiation Dose Assessment
  • Environmental Protection Programs
Technical Specifications
Item Parameter
Detector Type CsI(Tl) Scintillator + Semiconductor
Measured Radiation Type X-rays, Gamma rays (γ-rays)
Dose Rate Measurement Range 0.01 μSv/h ~ 1 Sv/h
Cumulative Dose Measurement Range 0.1 μSv ~ 10 Sv
Count Rate Measurement Range 20 cps ~ 100,000 cps
Sensitivity (¹³⁷Cs) ≥400 cps/(μSv/h)
Energy Response 48 keV ~ 3 MeV, <±30% (for ¹³⁷Cs)
Relative Intrinsic Error ≤±10%
Response Time 1 s
Alarm Threshold 0.2 μSv/h ~ 50 mSv/h continuously adjustable
Alarm Modes Audible, visual, vibration, LCD display
Battery Built-in lithium battery
Continuous Operating Time ≥130 h (static mode)
Protection Rating IP65
Operating Temperature -30℃ ~ +50℃
Dimensions 104 mm × 70 mm × 34 mm
Weight 280 g
Portable Gamma Survey Device with Dual Detector System, High Sensitivity 400 cps/(μSv/h), and IP65 Weather-Resistant for Environmental Monitoring Portable Gamma Survey Device with Dual Detector System, High Sensitivity 400 cps/(μSv/h), and IP65 Weather-Resistant for Environmental Monitoring
Key Advantages:
  • Dual Detector — Scintillator + semiconductor technology
  • High Sensitivity — 400 cps/(μSv/h) detection
  • Wide Range — 0.01 μSv/h to 1 Sv/h coverage
  • Portable Design — 280g lightweight device
  • Long Battery — 130 hours continuous operation
  • Environmental Ready — IP65 weather protection
