35mm Permanent Magnet Dc Motor 12V 35BYJ412 4 Phases 22.3:1 Ratio Customized For Toilet
35mm Permanent Magnet Dc Motor 12V 35BYJ412 4 Phases 22.3:1 Ratio Customized For Toilet
35mm Permanent Magnet Dc Motor 12V 35BYJ412 4 Phases 22.3:1 Ratio Customized For Toilet
35mm Permanent Magnet Dc Motor 12V 35BYJ412 4 Phases 22.3:1 Ratio Customized For Toilet
35mm Permanent Magnet Dc Motor 12V 35BYJ412 4 Phases 22.3:1 Ratio Customized For Toilet
35mm Permanent Magnet Dc Motor 12V 35BYJ412 4 Phases 22.3:1 Ratio Customized For Toilet
Specifications
Brand Name :
WEIGU
Model Number :
35BYJ412
Certification :
RoHS
Place of Origin :
China
MOQ :
1unit
Price :
$1.5~2.5/unit
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000Units/month
Delivery Time :
7-30 work days
Packaging Details :
Standard export package, or can be customized
Type :
Gearbox Stepper Motor
Rated Voltage :
12V
Gear Ratio :
1/22.3
Step Angle :
3.75°
Insulation Resistance :
100MΩ (MIN.)
Dielectric Strength :
600VAC 1mA 1S
Description

35mm Permanent Magnet Dc Motor 12V 35BYJ412 4 phases 22.3:1 ratio geared reducer stepping motor for smart toilet

This is a 35mm diameter permanent magnet stepper motor with gear ratio gearbox.

This is an uni-polar motor with 4 phases.

With low price and reliable quality, this motor is widely used in home appliance industries, such as air conditioning, smart home system, smart toilet and so on.

We provide customization service on gear ratio, coil resistance, phase number, and connector types.

Customers can customize motor’s parameter based on specific requirement

Customization options:

Model No.: 35BYJ412

Step angle:(1-2phase driving) 3.75°/22.3; (2-2 phase driving) 7.5°/step

Gear ratio: 22.3:1

Voltage:12V; gear ratio, gear material, output shaft, motor’s cap design customizable

Voltage

(V)

Resistance

(Ω)

Pull-in torque

100PPS

(mN*m)

Detent Torque

(mN*m)

Unload pull-in

Frequency

(PPS)

12

45

≥100

≥58.4

≥500

12

130

≥80

≥58.4

≥500

12

200

≥60

≥58.4

≥500

Design drawing(Unit:mm)

35mm Permanent Magnet Dc Motor 12V 35BYJ412 4 Phases 22.3:1 Ratio Customized For Toilet

Technical Features

Application Highlights

HVAC/R Valve Actuation Winding possibilities – Bipolar

Office Automation Printers, Copiers, Data storage Maintenance free - motor is brushless

Medical Applications Pill dispensing Analysers Cost effective - compact design, lower integration cost

Telecommunication Antennae positioning Switching lines Open loop control - No encoders necessary

Packaging and Shipping information:

Samples are packed with foam sponge inside paper box.

For mass production, products are packed in paper carton.

For sea shipping (Mass production), cartons are packed on pallet.

Shipping time:

By express(DHL/ UPS/ Fedex/ TNT): 5~12 days

By 4PX express: 10~20 days

Sea shipping: 40~60 days (depends on different countries)
