Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
Specifications
Brand Name :
TYHE
Model Number :
TJX38RO
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
OD38mm diameter
Voltage :
6v 12v 24v or customized
Speed :
1-1650rpm Customized
Torque :
8.5N.m
Gear material :
Steel gear
Commutation :
brushes
Type :
12v 24v DC Planetary Gear Motor
Keywords :
Good Price Small Size D38mm 12 Voltios 40kg.Cm Torque 200 Rpm Dc Planetary Gear Motor With Brake
Description

Products Description

Good Price Small Size D38mm 12 Voltios 40kg.Cm Torque 200 Rpm Dc Planetary Gear Motor With Brake

2D drawing

Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque


Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY3864 24 3200 80 2560 0.25 14.30 3.83 63.89 42.90 1.30
ZY3864 24 4000 120 3200 0.40 17.90 6.00 62.48 53.70 2.20
ZY3864 24 4500 130 3600 0.46 18.20 6.86 62.83 54.60 2.60
ZY3864 24 5000 160 4000 0.55 19.50 8.17 61.88 58.50 3.10
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-3200RPM Input 24V-4000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
28.2 90 3.7 691.9 3.45 47.62 142.86 864.9 5.40 59.61 178.82
28.2 90 5.2 492.3 3.45 66.92 200.77 615.4 5.40 83.77 251.32
37 81 13.7 186.9 3.10 158.69 476.06 233.6 4.86 198.64 595.91
37 81 19.2 133.3 3.10 222.39 667.18 166.7 4.86 278.38 835.14
37 81 26.9 95.2 3.10 311.58 934.75 119.0 4.86 390.02 1170.07
37 81 35.0 73.1 3.10 405.41 1216.22 91.4 4.86 507.47 1522.40
45.8 73 51.0 50.2 2.80 532.39 1597.17 62.7 4.38 666.42 1999.25
45.8 73 71.0 36.1 2.80 741.17 2223.51 45.1 4.38 927.76 2783.27
45.8 73 100.0 25.6 2.80 1043.90 3131.70 32.0 4.38 1306.70 3920.10
45.8 73 139.0 18.4 2.80 1451.02 4353.06 23.0 4.38 1816.31 5448.94
54.7 65.6 189.0 13.5 2.51 1772.97 5318.91 16.9 3.93 2219.31 6657.94
54.7 65.6 264.0 9.7 2.51 2476.53 7429.59 12.1 3.93 3099.99 9299.98
54.7 65.6 369.0 6.9 2.51 3461.52 10384.55 8.7 3.93 4332.95 12998.84
54.7 65.6 514.0 5.0 2.51 4821.73 14465.19 6.2 3.93 6035.59 15000.00
54.7 65.6 721.0 3.6 2.51 6763.56 15000.00 4.4 3.93 8466.27 15000.00
64 59 699.0 3.7 2.26 5897.46 15000.00 4.6 3.54 7382.14 15000.00
64 59 977.0 2.6 2.26 8242.95 15000.00 3.3 3.54 10318.10 15000.00
64 59 1367.0 1.9 2.26 11533.38 15000.00 2.3 3.54 14436.89 15000.00
64 59 1911.0 1.3 2.26 15000.00 15000.00 1.7 3.54 15000.00 15000.00
64 59 2672.0 1.0 2.26 15000.00 15000.00 1.2 3.54 15000.00 15000.00
64 59 3736.0 0.7 2.26 15000.00 15000.00 0.9 3.54 15000.00 15000.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-4500RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
28.2 90 3.7 973.0 6.17 60.61 181.82 1081.1 7.35 64.94 194.81
28.2 90 5.2 692.3 6.17 85.18 255.53 769.2 7.35 91.26 273.78
37 81 13.7 262.8 5.56 201.97 605.90 292.0 6.62 216.39 649.17
37 81 19.2 187.5 5.56 283.05 849.14 208.3 6.62 303.26 909.79
37 81 26.9 133.8 5.56 396.56 1189.68 148.7 6.62 424.89 1274.66
37 81 35.0 102.9 5.56 515.97 1547.91 114.3 6.62 552.83 1658.48
45.8 73 51.0 70.6 5.01 677.59 2032.76 78.4 5.96 725.99 2177.96
45.8 73 71.0 50.7 5.01 943.31 2829.92 56.3 5.96 1010.69 3032.06
45.8 73 100.0 36.0 5.01 1328.60 3985.80 40.0 5.96 1423.50 4270.50
45.8 73 139.0 25.9 5.01 1846.75 5540.26 28.8 5.96 1978.67 5936.00
54.7 65.6 189.0 19.0 4.50 2256.51 6769.53 21.2 5.36 2417.69 7253.06
54.7 65.6 264.0 13.6 4.50 3151.95 9455.85 15.2 5.36 3377.09 10131.26
54.7 65.6 369.0 9.8 4.50 4405.56 13216.69 10.8 5.36 4720.25 14160.74
54.7 65.6 514.0 7.0 4.50 6136.75 15000.00 7.8 5.36 6575.09 15000.00
54.7 65.6 721.0 5.0 4.50 8608.16 15000.00 5.5 5.36 9223.03 15000.00
64 59 699.0 5.2 4.05 7505.86 15000.00 5.7 4.82 8042.00 15000.00
64 59 977.0 3.7 4.05 10491.03 15000.00 4.1 4.82 11240.39 15000.00
64 59 1367.0 2.6 4.05 14678.85 15000.00 2.9 4.82 15000.00 15000.00
64 59 1911.0 1.9 4.05 15000.00 15000.00 2.1 4.82 15000.00 15000.00
64 59 2672.0 1.3 4.05 15000.00 15000.00 1.5 4.82 15000.00 15000.00
64 59 3736.0 1.0 4.05 15000.00 15000.00 1.1 4.82 15000.00 15000.00

Please let us know your requirements and we will provide you with transmission solutions.

Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque

Small D38mm 200Rpm 24V DC Gear Motor With Brake 40kg.Cm Torque
