Specifications
Brand Name :
SEEC
Model Number :
work roll and backup roll
Certification :
ISO
Place of Origin :
China
MOQ :
10
Delivery Time :
3-6months
Packaging Details :
Standard international package
Type :
work roll and backup roll
Material 1 :
cast iron and cast steel
application :
hot rolling mill
material 2 :
Pearlitic ductile cast iron roll
drawing :
as confirmed
standard :
ISO9001
Description

Adamite Steel Rolls Cast steel base adamite ductile iron mill roll

Main application:Roll is an important part of rolling mill,It mainly bears the influence of static load, wear and temperature change during rolling.

Product name Mill roll
Condition New
Fuel Gas, oil, diesel
Model 250-650
Voltage 380-440v
Size 3*2*4
Supply ability 1000Ton/per day
Project location China

Pearlitic ductile cast iron roll
Chemical Analysis
Designation of rolls Material code C Si Mn Ni Cr Mo Mg
Pearlitic ductile cast iron roll Ⅰ SGP Ⅰ 3.00-3.40 1.40-1.90 0.40-0.80 1.50-2.00 0.20-0.60 0.20-0.60 ≥0.04
Pearlitic ductile cast iron roll Ⅱ SGP Ⅱ 3.00-3.40 1.20-2.00 0.40-0.80 2.01-2.50 0.20-1.00 0.20-0.60 ≥0.04
Pearlitic ductile cast iron roll Ⅲ SGP Ⅲ 3.00-3.40 1.00-2.00 0.40-0.80 2.51-3.00 0.20-1.20 0.20-0.60 ≥0.04
Physical Properties
Designation of rolls Material code Barrel hardness Neck hardness Tenslle strength
Pearlitic ductile cast iron roll Ⅰ SGP Ⅰ 45-55 35-55 >450
Pearlitic ductile cast iron roll Ⅱ SGP Ⅱ 55-65 35-55 >450
Pearlitic ductile cast iron roll Ⅲ SGP Ⅲ 62-72 35-55 >450
Microstructure
Designation of rolls Material code Microstructure
Pearlitic ductile cast iron roll Ⅰ SGP Ⅰ Pearlite+cementite+small Graphite
Pearlitic ductile cast iron roll Ⅱ SGP Ⅱ Pearlite+cementite+small Graphite
Pearlitic ductile cast iron roll Ⅲ SGP Ⅲ Globular pearlite+carbide+graphite Or a small amount of pearlite
+bainite+carbide+sperical graphite
Application
Designation of rolls Material code Appllcation
Pearlitic ductile cast iron roll Ⅰ SGP Ⅰ Profiles,rods,wire and narrow strip mill thick,in the
rolling mill stand
Pearlitic ductile cast iron roll Ⅱ SGP Ⅱ Profiles,rods,wire and narrow strip mill thick,in the
rolling mill stand
Pearlitic ductile cast iron roll Ⅲ SGP Ⅲ Profiles,rods,wire and narrow strip mill thick,in the
rolling mill stand
