The NVIDIA MFP7E10-N050 is a high-performance, 50-meter Multimode Fiber (MMF) Optical Fiber Cable engineered for maximum-reach data center interconnections. This premium passive fiber cable features MPO-12/APC connectors on both ends, utilizing angled physical contact technology to minimize signal reflection for optimal data integrity in 400GbE, InfiniBand NDR, and NVLink environments. The MFP7E10 series delivers reliable, low-latency connectivity for switch-to-switch and switch-to-adapter configurations.
The MFP7E10 optical solution incorporates 8-degree angled APC polishing technology that significantly reduces optical back reflection below -35dB, critical for maintaining signal integrity in high-speed data transmission. This Optical Fiber Cable meets rigorous international standards including IEC 61754-7 for MPO connectors and is specifically engineered for compatibility with NVIDIA® Mellanox® networking ecosystems.
This passive fiber cable employs a precise Type-B crossover fiber arrangement where transmit channels (lanes 1-4) from one terminal connect to receive channels (lanes 9-12) on the opposite end. The APC polish with specialized 8-degree angled endfaces deflects internal optical back reflections, preventing signal distortion between compatible transceivers including MMA4Z00-NS OSFP DR8 modules.
Parameter | Value |
---|---|
Model | MFP7E10-N050 |
Length | 50 m |
Fiber Type | Multimode OM4 |
Connectors | MPO-12/APC (Female) |
Insertion Loss | ≤ 0.37 dB |
c | ≥ 35 dB |
Jacket Material | LSZH-OFNR |
Operating Temperature | 0°C to 70°C |
Minimum Bend Radius | 30 mm |
Cable Diameter | 3.0 ± 0.2 mm |
We provide comprehensive 24/7 technical consultation, global shipping options, and dedicated after-sales support. All products include standard manufacturer warranty and are sourced directly through certified distribution channels to ensure authenticity and performance.
Q: What is the maximum distance supported by the MFP7E10-N050?
A: This Optical Fiber Cable supports up to 50 meters for multimode connections with two patch panels in the link.
Q: Can I use this cable to connect NVIDIA switches to ConnectX-7 adapters?
A: Yes, the MFP7E10 passive fiber cable is specifically designed for switch-to-adapter configurations in NVIDIA environments.
Q: Is this compatible with MPO-12/UPC connectors?
A: No, MPO-12/APC connectors are not compatible with MPO-12/UPC due to different polishing angles.
Q: What protocols does this cable support?
A: This high-performance Optical Fiber Cable supports InfiniBand NDR, Ethernet, and NVLink protocols.
