MCP1600-E002E30 100Gb/s QSFP28 Direct Attach Copper Cable

1. Product Overview

The Mellanox MCP1600-E002E30 represents a high-performance passive Direct Attach Copper (DAC) solution engineered for 100Gb/s EDR InfiniBand and high-speed Ethernet implementations. This 2-meter passive fiber cable provides a reliable, cost-effective alternative to optical solutions for short-reach data center interconnections. Designed with precision engineering, this passive copper cable ensures optimal signal integrity while minimizing power consumption in dense network environments.

2. Key Characteristics

• Supports data rates up to 100Gb/s (4×25Gb/s channels)
• Extremely low power consumption: <0.1W
• Hot-pluggable QSFP28 form factor
• Compliant with SFF-8685, SFF-8636, and RoHS standards
• LSZH (Low Smoke Zero Halogen) protective jacket
• 30AWG conductor thickness for 2-meter reach
• Lead-free and halogen-free PCB construction

3. Technology & Standards

This advanced passive fiber cable complies with multiple industry standards including SFF-8685 for mechanical specifications and SFF-8636 for I²C management interface functionality. Supporting both InfiniBand EDR and Ethernet protocols, this passive copper cable ensures broad interoperability with Mellanox switching infrastructure and third-party hardware platforms. The cable architecture incorporates four shielded twinaxial copper pairs, each supporting 25 Gb/s data transmission rates.

4. Working Principle

The MCP1600-E002E30 operates as a passive electrical interconnect between QSFP28 ports, transmitting high-speed signals directly through copper conductors without requiring signal retiming or electronic amplification. The integrated EEPROM stores vital product information and performance characteristics, accessible through the host system's I²C interface, enabling seamless plug-and-play functionality and automatic system recognition capabilities.

5. Applications

Optimized for modern data center architectures, high-performance computing clusters, and enterprise network environments. Ideal deployment scenarios include:

• Intra-rack server-to-switch connections
• Adjacent rack interconnections
• Storage area network (SAN) infrastructure
• High-frequency trading network infrastructure
• AI and machine learning cluster interconnects
• Network appliance connectivity solutions

6. Specifications

7. Competitive Advantages

• Superior latency performance and reduced power consumption compared to active optical solutions
• Enhanced durability with optimized bend radius specifications
• Exceptional signal integrity with BER performance better than 1E-15
• Cost-efficient connectivity solution for reaches up to 2 meters
• Rigorous manufacturing testing ensures reliable out-of-box performance
• Comprehensive compatibility with Mellanox EDR infrastructure

8. Service & Support

All Mellanox passive copper cable products are backed by a 1-year limited hardware warranty. We provide global logistics support with standard 3-5 business day delivery, 24/7 technical assistance, and flexible OEM/ODM service options. Volume pricing structures available for enterprise deployments and large-scale infrastructure projects.

9. Frequently Asked Questions

Q: Is the MCP1600-E002E30 compatible with 100GbE Ethernet switches from various vendors?
A: Yes, this passive fiber cable is designed for compatibility with 100GbE and InfiniBand EDR switches supporting QSFP28 interfaces across multiple vendors.

Q: What is the maximum reliable distance for this specific DAC cable model?
A: This passive direct attach cable is engineered for optimal performance at distances up to 2 meters, making it an ideal passive copper cable solution for intra-rack connections.

Q: Does this passive fiber cable solution require external power or thermal management?
A: No, this is a passive direct attach cable that draws minimal power from the host port and requires no active cooling or external power sources.

Q: Can I deploy this cable in high-density rack environments?
A: Absolutely. The 30AWG construction and optimized bend radius make this passive copper cable ideal for high-density deployments where space constraints exist.

10. Installation Precautions

• Maintain minimum bend radius of 10x cable diameter near connector interfaces
• Ensure operating environment remains within specified temperature (0°C to 70°C) and humidity (5% to 85%) ranges
• Verify hardware compatibility specifications before installation and deployment
• Avoid sharp bends or torsional stress during installation to prevent internal conductor damage
• Implement proper ESD protection measures during handling and installation
• Confirm connector engagement and latching mechanism integrity before power activation
