Mellanox MCP7H50-H002R26: 200G HDR to Dual 100G HDR100 Breakout DAC Cable

Product Overview

The Mellanox MCP7H50-H002R26 is a high-performance Direct Attach Copper (DAC) breakout solution that serves as a superior alternative to traditional passive fiber cable systems. This innovative interconnect efficiently converts a single 200Gb/s InfiniBand HDR port into two independent 100Gb/s HDR100 connections, offering data centers an optimal combination of performance, power efficiency, and cost-effectiveness for high-density networking environments.

Technical Specifications

Technology Implementation

This advanced passive fiber cable alternative utilizes sophisticated 4×50Gb/s PAM4 modulation technology, delivering exceptional signal integrity across all transmission channels. The solution fully complies with InfiniBand Trade Association (IBTA) HDR standards and incorporates SFF-8665 and SFF-8636 specifications for seamless integration and comprehensive management via I²C interface, providing a robust alternative to traditional fiber optic systems.

Operational Methodology

The MCP7H50-H002R26 functions as an intelligent passive electrical bridge, efficiently routing high-speed signals from a single QSFP56 connector (supporting 200G HDR) to two independent QSFP56 connectors (each supporting 100G HDR100). This sophisticated passive fiber cable replacement maintains exceptional signal integrity through precision impedance-matched copper conductors (100Ω characteristic impedance) and advanced shielding technologies that effectively minimize crosstalk and electromagnetic interference, ensuring reliable data transmission.

Application Environments

This high-density interconnect solution is ideally suited for modern infrastructure requirements:

Competitive Advantages

The MCP7H50-H002R26 offers significant advantages over both active optical cables and previous-generation copper solutions:

• Economic Efficiency: Provides approximately 35-45% cost reduction compared to equivalent active optical solutions
• Power Optimization: Consumes less than 0.1W compared to 2-3W for active optical cables
• Enhanced Reliability: Passive design eliminates failure points associated with active components
• Reduced Latency: Electrical signal transmission offers lower latency than optical conversion systems
• Environmental Safety: LSZH jacket and halogen-free construction improve facility safety standards
• Thermal Management: Reduced power consumption decreases cooling requirements in dense configurations

Support Services

Mellanox provides comprehensive support infrastructure for the MCP7H50-H002R26:

• 1-year limited hardware warranty covering materials and manufacturing defects
• Global technical support network with expert assistance for integration challenges
• Custom configuration services for large-scale deployment scenarios
• Standard order fulfillment within 2-3 weeks with expedited options available
• Compatibility verification services for heterogeneous environments

Frequently Asked Questions

Installation Guidelines

To ensure optimal performance and longevity:

• Maintain minimum bend radius of 34mm for single bends and 68mm for repeated bends
• Avoid sharp bends, particularly near connector interfaces where stress is concentrated
• Implement proper ESD precautions during handling and installation procedures
• Verify compatibility with host system firmware and driver versions before deployment
• Operate strictly within specified temperature (0°C to 70°C) and humidity (5% to 85%) ranges
• Regularly inspect connectors for debris or damage before installation and during maintenance cycles
