Aruba 510 Series AP Q9H57A - High-Performance Wi-Fi 6 Access Point with External Antennas

1. Product Overview

The Aruba 510 Series AP (Model: Q9H57A) is a high-performance, dual-radio Wi-Fi 6 (802.11ax) access point designed for enterprise campus environments. It delivers a combined peak data rate of up to 2.69 Gbps, making it ideal for organizations with growing IoT and mobility demands. This AP supports advanced features such as OFDMA, MU-MIMO, and integrated Bluetooth 5 and Zigbee for IoT readiness.

2. Key Features

• Wi-Fi 6 (802.11ax) with up to 2.69 Gbps aggregate throughput
• 4x4:4 MU-MIMO in 5GHz, 2x2:2 in 2.4GHz
• OFDMA and MU-MIMO for enhanced multi-user efficiency
• Integrated Bluetooth 5 and Zigbee (802.15.4) for IoT deployment
• WPA3 and Enhanced Open security
• Aruba ClientMatch and AirMatch for AI-driven optimization
• Flexible mounting and plenum-rated for air-handling spaces

3. Core Technologies

The Aruba 510 Series AP leverages cutting-edge wireless technologies including OFDMA (Orthogonal Frequency-Division Multiple Access), MU-MIMO, and Target Wake Time (TWT) for power-efficient IoT communication. It also supports advanced RF management features such as Dynamic Frequency Selection (DFS) and Transmit Beamforming (TxBF).

4. Working Principle

The AP uses dual radios to simultaneously manage 2.4GHz and 5GHz bands. Through OFDMA, it divides channels into smaller resource units (RUs) to serve multiple clients efficiently. MU-MIMO allows concurrent data transmission to several devices. Integrated Bluetooth and Zigbee radios enable location services and IoT connectivity without additional hardware.

5. Applications

Ideal for enterprise campuses, educational institutions, healthcare facilities, and large retail environments. Supports high-density deployments, IoT sensor networks, asset tracking, and seamless roaming with Aruba’s AI-driven optimization.

6. Specifications

7. Advantages

• Superior Wi-Fi 6 performance with OFDMA and MU-MIMO
• Integrated IoT support reduces need for extra hardware
• AI-powered RF management with ClientMatch and AirMatch
• High client capacity: up to 512 devices per radio
• Enhanced security with WPA3 and TPM support

8. Service & Support

We offer lifetime hardware warranty, 24/7 technical support, and global shipping. Our team provides pre-sales consultation, configuration guidance, and post-sales troubleshooting. Bulk order discounts available.

9. Frequently Asked Questions

Q: What is the maximum range of this AP?
A: Range varies based on environment, but typical indoor coverage is up to 150 feet with external antennas.

Q: Does it support mesh networking?
A: Yes, when used with Aruba controllers or gateways.

Q: Can it be powered via PoE?
A: Yes, it supports 802.3af/at/bt PoE standards.

10. Precautions

• Ensure proper ventilation and operating temperature (0°C to 50°C).
• Use compatible PoE injectors or switches for full functionality.
• Verify regulatory domain settings for compliant channel usage.
• Avoid obstructing antenna paths for optimal performance.
