Aruba 510 Series AP-515 (RW) Wi-Fi 6 Access Point

1. Product Overview

The Aruba 510 Series Campus Access Points represent a significant leap in enterprise-grade wireless technology, delivering robust Wi-Fi 6 (802.11ax) performance to meet the escalating demands of modern IoT and mobile connectivity. With a combined peak data rate of up to 2.69 Gbps, these dual-radio access points ensure high-speed, reliable connectivity for dense device environments. The AP-515 model, part number Q9H62A, features integrated internal antennas and is designed for seamless indoor deployment, offering exceptional coverage and capacity.

2. Key Characteristics

• Wi-Fi 6 (802.11ax) with dual radios: 5GHz 4x4 MIMO and 2.4GHz 2x2 MIMO
• Integrated Bluetooth 5 and Zigbee for IoT readiness
• WPA3 and Enhanced Open security for robust network protection
• AI-powered ClientMatch technology for optimized client steering
• Orthogonal Frequency-Division Multiple Access (OFDMA) and MU-MIMO
• Target Wake Time (TWT) for improved IoT power efficiency
• Flexible power options: PoE (802.3af/at/bt) or DC input

3. Core Technologies

The Aruba 510 Series leverages advanced wireless standards including OFDMA, MU-MIMO, and 160 MHz channel bandwidth to maximize spectral efficiency and reduce latency. Built-in technologies such as AirMatch and Air Slice utilize machine learning for dynamic RF management and application assurance. The AP also supports advanced features like Transmit Beamforming (TxBF), Dynamic Frequency Selection (DFS), and Low-Density Parity Check (LDPC) for enhanced performance and reliability.

4. Working Principle

The access point operates by simultaneously managing multiple client devices using OFDMA, which divides channels into smaller resource units (RUs) to minimize contention. MU-MIMO allows downlink communication with up to four clients at once. ClientMatch technology intelligently steers devices to the best available band and access point, while AirSlice dynamically allocates radio resources based on configured SLAs, ensuring consistent application performance.

5. Application Scenarios

Ideal for high-density environments such as campuses, enterprises, healthcare facilities, and educational institutions. Supports IoT deployments through integrated Bluetooth and Zigbee radios. Suitable for both traditional Wi-Fi networks and modern location-based services, including asset tracking and indoor navigation.

6. Specifications

7. Advantages & Selling Points

The Aruba 510 Series Access Point offers superior performance with Wi-Fi 6 capabilities, including OFDMA and MU-MIMO, ensuring efficient multi-user handling. Its integrated IoT support eliminates the need for additional hardware. Advanced security features like WPA3 and Enhanced Open provide enterprise-grade protection. With AI-driven optimization and flexible management options, this AP delivers a future-proof solution for modern wireless networks.

8. Service & Support

Our company provides lifetime hardware warranty, 24/7 technical support, and global shipping. We offer competitive pricing and reliable supply chain management, ensuring timely delivery and post-sale assistance. Integration and configuration services are available upon request.

9. Frequently Asked Questions

Q: What is the maximum number of clients supported per radio?
A: Each radio supports up to 512 associated client devices and 16 BSSIDs.

Q: Does the AP support Power over Ethernet?
A: Yes, it supports PoE via 802.3af, at, or bt standards on the SmartRate port.

Q: Can this access point be used in outdoor environments?
A: No, the AP-515 is designed for indoor use only.

Q: Is Bluetooth 5 integrated into the AP?
A: Yes, the AP includes integrated Bluetooth 5 and Zigbee radios for IoT applications.

10. Precautions

• Ensure proper ventilation and avoid obstructing the AP's antennas.
• Use only approved power adapters or PoE injectors.
• Comply with local regulatory requirements for RF transmission.
• Do not expose to moisture, extreme temperatures, or direct sunlight.
• Regular firmware updates are recommended for security and performance.
