RUCKUS ICX 8200-C08PF: Compact 8-Port Gigabit PoE+ Stackable Switch

The RUCKUS ICX 8200-C08PF is an enterprise-class compact stackable access switch designed for high-density Wi-Fi 6/6E/7 and IoT deployments. It offers 8× Gigabit Ethernet PoE+ ports, 2× 10 GbE SFP+ uplinks, and a 124W PoE budget, making it ideal for space-constrained environments requiring reliable power and performance.

Key Features

• 8× 10/100/1000 Mbps RJ45 PoE+ ports (802.3at, 30W per port)
• 2× 1/10 GbE SFP+ uplink/stacking ports
• 124W total PoE power budget
• Compact, fanless design for quiet operation
• Stackable with up to 12 units per stack
• Advanced Layer 3 features (with license)
• 3-year remote TAC support and limited lifetime warranty

Core Technologies & Standards

The ICX 8200-C08PF supports a wide range of enterprise-grade technologies including:

• PoE/PoE+ (802.3af/at)
• Energy Efficient Ethernet (802.3az)
• VXLAN for network segmentation
• IPv4/IPv6 static routing, RIP, OSPF (with license)
• sFlow, SNMPv3, SSHv2, ACLs, 802.1X

How It Works

The switch operates as a high-performance access layer device, providing Power over Ethernet to connected devices such as wireless access points, IP phones, and cameras. It uses stacking technology to combine multiple physical switches into a single logical unit, simplifying management and increasing redundancy. Traffic is routed and prioritized using advanced QoS and ACL policies.

Typical Applications

• Small to medium-sized business networks
• Wi-Fi 6/6E/7 access point deployments
• Classroom, retail, or clinic connectivity
• Edge switching in IoT environments
• Branch office networking

Specifications & Selection Guide

Advantages & Differentiators

• High PoE density in a compact form factor
• Future-proof stacking with 10G uplinks
• Quiet, fanless operation suitable for office environments
• Advanced security and management features
• 3-year support and lifetime warranty included

Service & Support

All RUCKUS ICX 8200 switches come with 3 years of remote TAC support and a limited lifetime warranty. Next-business-day advanced replacement is available in eligible regions. Professional services and extended support plans can be added.

Frequently Asked Questions

Q: Can the ICX8200-C08PF power Wi-Fi 6 access points?
A: Yes, its PoE+ ports support up to 30W per port, sufficient for most Wi-Fi 6 and Wi-Fi 6E access points.

Q: Is the switch stackable?
A: Yes, it supports stacking with up to 12 ICX 8200 series switches using SFP+ ports.

Q: Does it support Layer 3 routing?
A: Basic Layer 3 features are included; advanced features like OSPF and VRRP require a license.

Important Notes

• Ensure adequate power and cooling for PoE loads.
• Use compatible SFP+ modules for uplinks and stacking.
• Verify firmware compatibility for advanced features.
• Complies with FCC, CE, RoHS, and other international standards.
