Long Wavelength 8~12um f13mm F1.2 IR Lens M20x0.5 mount Prime Lens for sensor 256*192 12um
Long Wavelength 8~12um f13mm F1.2 IR Lens M20x0.5 mount Prime Lens for sensor 256*192 12um
Specifications
Place of Origin :
China
Model Number :
LWIR1312
Payment Terms :
T/T, Western Union, Moneygram, Paypal
IR Lens :
Long Wavelength IR Lens
Delivery Time :
7-15 work days
Aperture :
F1.2
Supply Ability :
Samples available
Sensor :
256*192 12um
Packaging Details :
Standard
Focal Length :
13mm
MOQ :
100pcs
Brand Name :
CCOM LENS
Wavelength :
8~12um
Description

Long Wavelength 13mm F1.2 8~12um IR Lens for sensor 256*192 12um, Prime Lens f13mm F1.2 M20x0.5 mount IR Lens

Model no.: LWIR1312

Sensor: 256*192 um
Transmission(8-12μm): ≥88%
Wavelength: 8~12um
Focal length: 13mm

F.R.: >3m
Aperture: F1.2
Mount: M20×0.5-6g

Distortion: ≤-3%
F.O.V (D*H*V): 42.6°*34.1°*25.56°
RI: ≥86%
F.F.L.: 8.5mm
M.B.F.L.: 7.0mm
Dimension: Ø20 x L15.3mm

Sealing: IP67 (first mirror glass)

Tip:
- For more IR lenses, please feel free to contact us at sales01@megapixellenses.com
