Key Specifications

• Model: 3VA2463-5HL32-0AA0
• Brand: Siemens
• Series: SENTRON
• Type: Molded Case Circuit Breaker
• Frame Size: IEC 630
• Breaking Capacity Class: M
• Rated Insulation Voltage: 800 V
• Rated Operating Voltage: 690 V (AC 50/60 Hz)
• Pole Configuration: 3-pole
• Rated Continuous Current (In): 630 A
• Overload Protection Range (Ir): 250 A to 630 A
• Short-Circuit Protection Range (Ii): 1.5 to 9 times In
• Short-Circuit Breaking Capacity (Icu):
  • 240 V: 85 kA
  • 415 V: 55 kA
  • 440 V: 55 kA
  • 500 V: 36 kA
  • 690 V: 6 kA
• Operating Short-Circuit Current Breaking Capacity (Ics): Same as Icu
• Short-Circuit Current Making Capacity (Icm):
  • 240 V: 187 kA
  • 415 V: 121 kA
  • 440 V: 121 kA
  • 500 V: 75.6 kA
  • 690 V: 9 kA
• Mechanical Service Life: 20,000 switching cycles
• Electrical Endurance:
  • 380/415 V: 5,000 switching cycles
  • 690 V: 3,500 switching cycles
• Power Loss:
  • Maximum: 162 W
  • Per Pole at Rated Current: 54 W
• Dimensions:
  • Height: 248 mm (9.76 in)
  • Width: 138 mm (5.43 in)
  • Depth: 110 mm (4.33 in)
• Weight: 5.098 kg
• Protection Class: IP40 on the front
• Ambient Temperature:
  • During Operation: -25°C to 70°C
  • During Storage: -40°C to 80°C.

Features and Benefits

• High Precision: Ensures precise protection against overloads and short circuits.
• Robust Construction: Designed for long-term reliability in demanding industrial environments.
• Wide Operating Range: Suitable for a wide range of operating conditions, including different temperatures and voltages.
• Compliance with Standards: Meets international standards for safety and environmental compliance.
• Line Protection: Provides reliable protection for electrical circuits in industrial applications.

Applications

• Electrical Systems: For precise control and protection in electrical circuits.
• Material Handling Equipment: Such as forklifts and pallet trucks.
