GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
Specifications
Model Number :
GTA15-25
MOQ :
1PC
Payment Terms :
TT ,western union ,paypal
Supply Ability :
1000
Delivery Time :
3-7 days
Packaging Details :
neutral packing
Size :
40.40/56.02mm
Type :
Turbochargers
Description
1.Model:GTA15-25 forward
2.GTA15-25 40.40/56.02mm 6+6 blades 701374-0003 1102-022-402 turbo Billet/milling/aluminum 2618 compressor wheel
3.Size:
Nose diameter:11.93mm
Inducer:40.40mm
exducer:56.02mm
Tapered tip exducer:58.34mm
Tip height:4.57mm
Superback:2.39mm
bore size :5.08mm
bore type:through
Overall height:27.00mm
Cutback:2.0mm
Trailing Angle:55 degree
Blades height:22.40mm
Splitter height:15.55mm
Sp height angle:-3.30
6+6 blades
forward rotation
It is custom size ,please check carefully before buying.
Tapered tip Angle:18 degree
4.High quality and competitive price.
5.if you want more details, please send email to me.
All the compressor wheels have been balanced.

Skype: maxabledieselparts

Wechat/Whatsapp:+86-18018657719

GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel GTA15-25 40.40/56.02mm 6+6 blades701374-00031102-022-402 turbo milling/aluminum 2618/billet compressor wheel
