Specifications
Brand Name :
NO
Model Number :
GT15-25
Place of Origin :
CHINA
MOQ :
1PC
Payment Terms :
TT/western union/paypal
Supply Ability :
1000
Delivery Time :
3-7 days
Packaging Details :
neutral packing
Description

1. MODEL:GT15-25 reverse

2.GT15-25 reverse 49.70/67.40mm 6+6 blades high performance turbo billet/milling/aluminum 2618 compressor wheel

3.Size:

Nose diameter:12.00mm

inducer:49.70mm

Exduder:67.40mm

Tapered tip exducer:71.70mm

Tip height:4.72mm

Superback:3.80mm

Overall height:35.00mm

bore size :5.08mm

Trailing Angle:55

Cutback:4.70mm

SP Height Angle:-6.40

Splitter height:12.10mm

Blade height:29.00mm

Tapered Tip Angle:30 degree

6+6 blades

reverse rotation

it is custom size ,please check carefully before buying.

4.High quality and competitive price.

5.if you want more details, please send email to me.

We can produce as your requirement.

The minumum order is 5pcs .

The more models we also have.

skype:maxabledieselparts

wechat/whatsapp:+86-18018657719
