Specifications
Brand Name :
NO
Model Number :
K04
MOQ :
1PC
Payment Terms :
TT ,western union ,paypal
Supply Ability :
1000pcs
Delivery Time :
3-7 days
Packaging Details :
neutral packing
Description

1.Model: K04 forward
2.K04 5306-123-2201/9A212303152 42.90/54.96mm 6+6 blades high performance aluminum 2618/milling /billet compressor wheel

for 5304-970-0163/5304-970-0262/5304-970-0265/5304-970-0279/5304-970-0295/5304-970-0299/5304-970-0164/5304-970-0263/5304-970-0266/5304-970-0280/5304-970-0296/5304-970-0298 Porsche 911 Turbo (991) Carrera 3.0, 9A2, Year 2017​

3.SIZE:

Nose diameter:11.90mm

inducer:42.90mm

Exducer:54.96mm

Tapered tip exducer:56.44mm

Tip height:4.63mm

Superback:2.65mm

Overall height:27.80mm

bore size :4.61mm

bore type:through

Trailing angle:45 degree

Cutback:6.70mm

SP Height angle:-12.00

Blades height:20.19mm

Splitter height:10.55mm

6+6 blades

forward rotation

Tapered tip angle:11.5 degree

Fits OE Compressor Housing

4.Good quality and competitive price

5.Please send email to me or talk to me on online ,if you want to know more details.

All the billet compressor wheels have been balanced.

Skype: maxabledieselparts

Wechat/Whatsapp:+86-18018657719
