50KN M 80KN M Composite Geo Grid Ground Grid Polyethylene
50KN M 80KN M Composite Geo Grid Ground Grid Polyethylene
50KN M 80KN M Composite Geo Grid Ground Grid Polyethylene
50KN M 80KN M Composite Geo Grid Ground Grid Polyethylene
50KN M 80KN M Composite Geo Grid Ground Grid Polyethylene
50KN M 80KN M Composite Geo Grid Ground Grid Polyethylene
Specifications
Material :
Polypropylene PP High Density Polyethylene HDPE
Elongation :
≤10 percent
Supply Ability :
9999999㎡/MONTH
Standard :
GB T17689
Packaging Details :
Woven fabric packaging
Delivery Time :
5 days
Payment Terms :
T/T
Application :
Road and Retaining Wall
Place of Origin :
China
Feature :
High Strength Load Bearing
Product Name :
Uniaxial Plastic Geogrid
MOQ :
1000pcs
Structure :
Uniaxial Grid
Brand Name :
YPEP
Tensile Strength :
35 to 200 KN m
Description
High Strength PP HDPE Uniaxial Plastic Geogrid for Road Reinforcement Retaining Wall Soil Stabilization
Product Description

Uniaxial Plastic Geogrid is a high performance geosynthetic material designed for soil reinforcement and load bearing applications. It is manufactured by extruding polymer sheets and stretching them in one direction to form a highly oriented grid structure with excellent tensile strength.

This geogrid is specifically engineered to provide superior reinforcement in one principal direction, making it ideal for applications such as retaining walls, embankments, and subgrade stabilization. Its unique structure allows soil particles to interlock with the grid apertures, forming a strong composite system that distributes loads efficiently.

Compared with traditional materials, uniaxial geogrids significantly reduce differential settlement and prevent structural deformation. They also improve construction efficiency by reducing the need for imported fill materials.

The product is resistant to UV exposure, chemical corrosion, and biological degradation, ensuring long service life even in harsh environments. It performs exceptionally well under cyclic loading conditions, making it suitable for heavy traffic infrastructure.

Technical Specification
Model Material Tensile Strength KN m 2 percent Strength 5 percent Strength Elongation
TGDG35 PP ≥35 ≥10 ≥22 ≤10
TGDG50 PP ≥50 ≥12 ≥28 ≤10
TGDG80 PP ≥80 ≥26 ≥48 ≤10
TGDG120 PP ≥120 ≥36 ≥72 ≤10
TGDG160 PP ≥160 ≥45 ≥90 ≤10
TGDG200 PP ≥200 ≥56 ≥112 ≤10
TGDG35 HDPE ≥35 ≥7.5 ≥21.5 ≤11.5
TGDG80 HDPE ≥80 ≥21 ≥40 ≤11.5
TGDG160 HDPE ≥160 ≥47 ≥93 ≤11.5
50KN M 80KN M Composite Geo Grid Ground Grid Polyethylene
Why Choose Us
  • Advanced production technology ensures consistent strength
  • Full range of specifications for global projects
  • Strict quality inspection before shipment
  • OEM and custom solutions available
  • Fast delivery and stable supply chain
FAQ

Q What is the main advantage of uniaxial geogrid
A It provides high strength in one direction for reinforcement.

Q Can it be used for retaining walls
A Yes it is widely used in reinforced soil walls.

Q What material is better PP or HDPE
A PP offers higher stiffness while HDPE provides better flexibility.
