160kN/M Flexible Geotextile Bag Concrete Formwork Geotextile Sandbags Slope Protection
160kN/M Flexible Geotextile Bag Concrete Formwork Geotextile Sandbags Slope Protection
160kN/M Flexible Geotextile Bag Concrete Formwork Geotextile Sandbags Slope Protection
160kN/M Flexible Geotextile Bag Concrete Formwork Geotextile Sandbags Slope Protection
160kN/M Flexible Geotextile Bag Concrete Formwork Geotextile Sandbags Slope Protection
160kN/M Flexible Geotextile Bag Concrete Formwork Geotextile Sandbags Slope Protection
Specifications
Strength :
≥90 kN/m
Seam Strength :
≥160 kN/m
Function :
Formwork reinforcement
Payment Terms :
T/T
Color :
Gray White
UV Resistance :
≥90%
Packaging Details :
Woven fabric packaging
MOQ :
1000pcs
Elongation :
Low
Supply Ability :
9999999㎡/MONTH
Place of Origin :
China
Thickness After Filling :
12–50 cm
Delivery Time :
5 days
Brand Name :
YPEP
Material :
PP Polyester
Description
Flexible Geotextile Bag Concrete Formwork Underwater Construction Slope Protection Solution
Product Description

Flexible geotextile bags serve as an innovative formwork system for concrete placement in complex environments. The fabric acts as a mold, shaping the concrete while providing reinforcement through its high tensile strength.

This system is particularly suitable for underwater construction where traditional formwork is difficult to implement. The bag adapts to irregular surfaces, ensuring close contact and improved structural integrity.

Compared with rigid concrete panels, geotextile bags offer better resistance to cracking and displacement due to their flexible nature.

Technical Specifications
Property Unit Value
Grammage g/m² ≥650
Tensile Strength MD kN/m ≥90
Tensile Strength CD kN/m ≥90
Elongation MD/CD % ≤15 / 12
2% Tensile Strength MD kN/m ≥15
5% Tensile Strength MD kN/m ≥37
CBR Strength kN ≥8.5
Seam Strength kN/m ≥160
UV Resistance % ≥90
Opening Size O90 mm ≤0.425
Permeability Q50 L/m²/s ≥25
160kN/M Flexible Geotextile Bag Concrete Formwork Geotextile Sandbags Slope Protection160kN/M Flexible Geotextile Bag Concrete Formwork Geotextile Sandbags Slope Protection
Applications
  • Underwater construction
  • Canal lining
  • Emergency flood repair
Why Choose Us
  • Advanced weaving process
  • Flexible installation
  • Lower project cost
FAQ

How do geotextile bags work
They act as flexible molds filled with concrete forming a stable protective layer
