High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth
High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth
High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth
High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth
High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth
High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth
High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth
High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth
Specifications
Material :
Polypropylene PP Polyester PET
Length :
50m-100m
Function :
Separation Filtration Reinforcement Protection
Technology :
Woven Monofilament Process
Weight Range :
100gsm-800gsm
Brand Name :
YPEP
Payment Terms :
T/T
Color :
Black White Green Customized
Place of Origin :
China
Delivery Time :
5 days
Product Name :
Woven Geotextile
MOQ :
1000pcs
Packaging Details :
Woven fabric packaging
Width :
1m-9m
Supply Ability :
9999999㎡/MONTH
Description

High Strength PP Woven Geotextile Road Reinforcement Fabric UV Resistant Woven Geotextile Supplier

Product Introduction

Woven Geotextile is a durable and permeable geosynthetic fabric manufactured from high-strength polypropylene or polyester yarns through precision weaving technology. Designed for civil engineering and infrastructure reinforcement projects, this material provides excellent separation, filtration, drainage, and reinforcement performance in demanding construction environments.

Compared with traditional soil stabilization methods, woven geotextile significantly improves the bearing capacity of weak foundations while reducing construction costs and extending project service life. The woven structure offers high tensile strength in both machine and cross-machine directions, allowing the fabric to distribute loads evenly and minimize differential settlement.

The product is widely used in highway construction, railway foundations, retaining wall reinforcement, coastal engineering, landfill projects, airport runways, and mining applications. Due to its superior permeability, water can pass through the fabric efficiently while soil particles remain stable, preventing erosion and maintaining structural integrity.

Manufactured with UV-stabilized polymer materials, woven geotextile provides excellent resistance to aging, corrosion, microbial attack, and chemical degradation. Even in harsh environmental conditions such as acidic soil, alkaline water, or freeze-thaw cycles, the product maintains stable physical performance over long-term use.

Our factory offers customized woven geotextile solutions according to project requirements, including customized width, roll length, tensile strength, weight, color, and packaging. OEM branding and private label services are also available for global distributors and construction material importers.

Technical Specification Table

Item Unit 100gsm 150gsm 200gsm 300gsm 400gsm 600gsm 800gsm
Material - PP PP PP PET PET PET PET
Mass Per Unit g/m² 100 150 200 300 400 600 800
Tensile Strength MD KN/m 4.5 7.5 10 15 20 30 50
Tensile Strength CMD KN/m 4.5 7.5 10 15 20 30 50
Elongation At Break % 20-80 20-80 20-80 30-80 30-80 30-80 40-80
CBR Burst Strength KN 0.8 1.6 1.9 2.9 3.9 6.4 8.5
Tear Resistance KN 0.14 0.21 0.28 0.42 0.56 0.82 1.25
Permeability Coefficient cm/s 10⁻¹-10⁻³ 10⁻¹-10⁻³ 10⁻¹-10⁻³ 10⁻¹-10⁻³ 10⁻¹-10⁻³ 10⁻¹-10⁻³ 10⁻¹-10⁻³
Equivalent Opening Size O90 mm 0.05-0.20 0.05-0.20 0.05-0.20 0.05-0.20 0.05-0.20 0.05-0.20 0.05-0.20
Roll Width m 1-9 1-9 1-9 1-9 1-9 1-9 1-9

High Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile ClothHigh Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile ClothHigh Strength Geotextile Weed Membrane PP Woven UV Resistant Geotextile Cloth

Product Advantages

Excellent Soil Separation Performance
The woven structure effectively separates aggregate layers from weak soil foundations, preventing material mixing and improving structural stability.

Outstanding Reinforcement Capability
High tensile strength allows the fabric to distribute loads uniformly, helping reduce rutting and settlement in roads and embankments.

Superior Water Permeability
The porous woven structure permits efficient water flow while preventing soil particle migration, maintaining long-term drainage performance.

Long Service Life
Manufactured with anti-aging polymer fibers, the product resists UV radiation, corrosion, microbial damage, and chemical erosion.

Cost Effective Construction
Easy transportation and installation help contractors reduce labor intensity, shorten construction periods, and lower overall engineering costs.

Wide Engineering Compatibility
Suitable for roads, railways, airports, ports, landfills, retaining walls, and hydraulic engineering applications.

Common Applications

Highway and road base reinforcement
Railway ballast separation
Airport runway stabilization
Landfill lining systems
Riverbank erosion control
Retaining wall reinforcement
Mining and tailings drainage
Agricultural water conservancy projects
Coastal embankment protection
Subgrade stabilization engineering

Packaging Information

Packaging Type Width Length Loading Capacity 20GP Loading Capacity 40HQ
Standard Roll 2m 50m 300 Rolls 750 Rolls
Standard Roll 4m 50m 180 Rolls 420 Rolls
Jumbo Roll 6m 100m 80 Rolls 210 Rolls
Customized Package Customized Customized Available Available

Why Choose Us

We are a professional geosynthetics manufacturer with rich export experience in Europe, Southeast Asia, Africa, South America, and the Middle East. Our woven geotextile products are manufactured under strict quality control systems and tested according to international engineering standards.

Advanced weaving production lines
Stable raw material sourcing system
OEM and ODM customization support
Competitive wholesale prices
Professional export documentation
Fast production and shipment
Experienced technical support team
Reliable after-sales service

We cooperate with contractors, distributors, engineering companies, and infrastructure project suppliers worldwide. Whether you require standard woven geotextile rolls or customized specifications, we can provide efficient and professional solutions.

FAQ

What is woven geotextile mainly used for

Woven geotextile is mainly used for soil separation, reinforcement, stabilization, filtration, and drainage in civil engineering and infrastructure projects.

What is the difference between PP and PET woven geotextile

PP woven geotextile has excellent chemical resistance and lightweight properties, while PET woven geotextile provides higher tensile strength and dimensional stability.

Can woven geotextile be customized

Yes. Width, roll length, tensile strength, color, packaging, and private label printing can all be customized according to project requirements.

Is woven geotextile resistant to UV exposure

Yes. Our woven geotextile products contain UV stabilizers that improve weather resistance and extend outdoor service life.

How long can woven geotextile last underground

Under proper installation conditions, woven geotextile can maintain stable performance for more than 20 years in underground applications.
