200gsm 300gsm Woven Geotextile 0.8mm - 1.9mm Heavy Duty Geotextile Membrane
200gsm 300gsm Woven Geotextile 0.8mm - 1.9mm Heavy Duty Geotextile Membrane
200gsm 300gsm Woven Geotextile 0.8mm - 1.9mm Heavy Duty Geotextile Membrane
200gsm 300gsm Woven Geotextile 0.8mm - 1.9mm Heavy Duty Geotextile Membrane
200gsm 300gsm Woven Geotextile 0.8mm - 1.9mm Heavy Duty Geotextile Membrane
200gsm 300gsm Woven Geotextile 0.8mm - 1.9mm Heavy Duty Geotextile Membrane
Specifications
Material :
Polyester PET Yarn
Brand Name :
YPEP
Weight :
120gsm to 800gsm
Application :
Soft Soil Reinforcement Road Base
Function :
Reinforcement Separation Filtration
Packaging Details :
Woven fabric packaging
Strength Range :
10KN/m to 120KN/m
Payment Terms :
T/T
Product Name :
Woven Geotextile Fabric
Delivery Time :
5 days
Place of Origin :
China
Width :
2m to 8m
Supply Ability :
9999999㎡/MONTH
Length :
50m to 200m
MOQ :
1000pcs
Description

Heavy Duty PET Woven Geotextile Soil Stabilization Woven Geotextile

Product Introduction

PET woven geotextile is a durable geosynthetic reinforcement material manufactured from high-tenacity polyester yarns through precision weaving technology. The product combines excellent tensile strength, low elongation, and superior dimensional stability, making it an ideal solution for road stabilization, embankment reinforcement, railway construction, and erosion control projects.

Compared with ordinary nonwoven fabrics, woven geotextile has stronger load-bearing capacity and better reinforcement performance. The tightly interlocked woven structure distributes loads evenly across the subgrade, preventing soil deformation and settlement. This improves pavement lifespan and minimizes maintenance costs.

The polyester woven geotextile offers excellent creep resistance under long-term loading conditions. Even in demanding environments such as highways, ports, airport runways, and industrial yards, the fabric maintains stable mechanical properties for many years.

Another major advantage is its chemical stability. PET woven geotextile can resist acids, alkalis, microorganisms, and underground moisture, ensuring long-term performance in aggressive soil conditions. It also demonstrates good UV resistance and weather resistance for outdoor construction projects.

The product is lightweight and easy to install. Rolls can be quickly deployed on-site, significantly improving construction efficiency and reducing labor costs. It is suitable for both temporary and permanent engineering works.

Technical Data Table

Item Unit 200gsm 300gsm 400gsm 500gsm
Tensile Strength MD KN/m 20 35 50 65
Tensile Strength CMD KN/m 20 35 50 65
Elongation % 18 20 22 25
Tear Strength KN 0.25 0.45 0.65 0.90
CBR Burst Strength KN 1.8 3.0 4.5 6.5
Permeability cm/s 0.025 0.020 0.018 0.015
Thickness mm 0.8 1.1 1.5 1.9
UV Retention % 80 80 80 80

Performance Advantages Table

Advantage Description
High Strength Excellent load distribution
Low Elongation Reduce subgrade settlement
Chemical Resistance Suitable for aggressive soil
Lightweight Easy transportation
Long Lifespan More than 20 years
Good Filtration Prevent soil migration

200gsm 300gsm Woven Geotextile 0.8mm - 1.9mm Heavy Duty Geotextile Membrane200gsm 300gsm Woven Geotextile 0.8mm - 1.9mm Heavy Duty Geotextile Membrane

FAQ

Q1. Is woven geotextile suitable for soft soil stabilization?

Yes. Woven geotextile is widely used to improve soft subgrade bearing capacity and reduce settlement.

Q2. What is the difference between woven and nonwoven geotextile?

Woven geotextile focuses more on reinforcement and tensile strength, while nonwoven geotextile emphasizes filtration and drainage.

Q3. Can PET woven geotextile resist UV exposure?

Yes. UV stabilizers are added during production for better weather resistance.

Q4. What roll sizes are available?

Common widths range from 1m to 8m, and lengths can be customized.

Q5. Is OEM packaging available?

Yes. Customized labels and packaging are supported.
