16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
Specifications
Brand Name :
Masing Motor
Model Number :
MS-PG16F050
Certification :
ISO,CE,ROHS ,16949
Place of Origin :
China
MOQ :
1000
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100000piece/per month
Delivery Time :
3-5 work weeks
Packaging Details :
Carton Box
Shaft type :
Round,Flat ,D-Cut,with hole ,with gear
Shaft diameter :
φ3mm
Gearbox Diameter :
φ16mm Gearbox
Direction of motor :
CW &CCW available
Rated voltage :
3v-24v
Gearbox type :
Planetary Gearbox
Micro Motor :
FF-050 dc brushed motor
Product name :
16mm dc planetary gear motor
Rated speed :
5rpm-4000rpm
reduction ratio :
1:4 to 1:1296
Description
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
High-quality micro DC planetary geared motor offering excellent efficiency and performance for various industrial and commercial applications.
Product Features
  • High Efficiency: 90%-65% efficiency rating
  • Motor Model: FF-030 or FF-050
  • Rated Speed: 5rpm - 4000RPM (customizable)
  • Constant rotating speed with custom specifications available
  • Compact Size: 16mm diameter planetary gear DC motor
  • Certifications: CE, RoHS, IOS9001, REACH, 16949
  • Low noise operation with high torque output
  • Motor Type: Brush Motor (Metal brush or Carton brush)
  • Direction: CW & CCW available
  • Working Temperature: -40°C to +60°C
  • Rated Power: 1W-5W, Maximum torque: 5KG.cm
Technical Specifications
  • Speed (RPM): 5rpm-4000rpm
  • Continuous Current: 0.01-0.09A
  • Efficiency: 90%-65%
  • Place of Origin: Guangdong, China
  • Brand Name: Masing Motor
  • Model Number: MS-PG16F050
  • Motor Type: Brushed Motor
  • Rated Torque: 0.01-5kg.cm
  • Construction: Permanent Magnet
  • Commutation: Brush
  • Protection: Totally Enclosed
  • Shaft Diameter: φ3mm, D-cut
  • Gearbox Diameter: φ16mm
  • Noise Level: ≤55DB
  • Shaft Type: Round, Flat, D-cut or Customized
  • Gearbox Material: Metal Gearbox Rohs
Product Images
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox 16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
Applications
Intelligent household appliances, office automation, automotive, medical, personal care, robot, electronic lock, industrial automation, door-lock, robots, SMART HOME, Electric Bicycle Lock, Cosmetic Instrument.
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
Performance Parameters
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
ModelVoltageNo-load SpeedNo-load CurrentOn-load SpeedOn-load CurrentStall TorqueStall CurrentGear Ratio
MS-16P050-46V14000.0911300.131.60.654
MS-16P050-166V3500.092850.135.10.6516
MS-16P050-246V2350.091900.137.50.6524
MS-16P050-646V900.1750.1413.20.6564
MS-16P050-966V550.1500.1419.90.6596
MS-16P050-2566V220.1180.1439.70.65256
MS-16P050-3846V150.1120.14600.65384
MS-16P050-5766V90.180.14890.65576
MS-16P050-8646V60.1250.151340.65864
MS-16P050-12966V40.1230.151960.651296
Packaging & Delivery
  • Packaging: Strong Carton 200pcs/box, or customized
  • Port: Shenzhen/Guangzhou/Shanghai
  • Selling Units: Single item
  • Package Size: 37×27×24cm
  • Gross Weight: 85G
  • Supply Ability: 100,000 pieces per month
Lead Time
Quantity (pieces)1 - 100101 - 1000> 1000
Lead Time (days)1015To be negotiated
Samples
  • Maximum order quantity: 1 piece
  • Sample price: $15/piece
Certifications
16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox 16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox 16mm Micro DC Motor PG16-050SH 6v 12v With Gear Reducer Planetary Gearbox
Frequently Asked Questions
Q1: How can I get the price?
A1: We usually quote within 24 hours after we get your inquiry (Except weekend and holidays). If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.
Q2: Can I buy samples placing orders?
A2: Yes. Please feel free to contact us.
Q3: What is your lead time?
A3: It depends on the order quantity and the season you place the order. Usually we can ship within 7-15 days for small quantity, and about 30 days for large quantity.
Q4: Do you accept customize?
A4: Sure, as we have a strong design team, any problems will get our technical answer.
Q5: What kind of data do I need to provide if I want to order?
A5: Please kindly tell us your voltage, speed, torque and overall dimension.
Q6: What if I don't know the above data?
A6: Please contact our salesman to handle, we'll answer your questions patiently.
