Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M
Specifications
Brand Name :
OUCO
Model Number :
OUCO-8T16M-KB
Certification :
CCS/ABS/RS/BV/LR/DNV GL/NK
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 sets per year
Delivery Time :
3 months
Packaging Details :
Shipping Container/Wood Crate/nude
Product :
8T16M Offshore Knuckle Boom AHC Crane For Sale
Model :
Knuckle Boom Crane
Quality :
Heat and freeze-proof, explosion-proof and radiation-proof, IP56
Color :
Blue/White/Yellow/other
Function :
360° Slewing/Lifting/Luffing/Knuckle
Test video :
Provided
Custom :
Accetp
Application :
Offshore Support Vessels, floating platforms, oil drilling rig, pipe-laying vessels
Description

8T16M Offshore Knuckle Boom AHC Crane For Sale

OUCO 8-ton 16-meter Folding Boom Offshore Crane, meticulously designed for Russian marine needs. Built to endure extreme cold at -40°C, this crane boasts hydraulic and electrical components designed for wider temperature ranges. Equipped Active Heave Compensation System ensures safe and efficient operation in any environment.

Certified by the Russian Classification Society (RS), this crane offers the convenience of wireless remote control operation. At OUCO, customization is key. We tailor ship cranes to your specifications – from structure to boom length, torque, and sea state level. Can be installed in Offshore Support Vessels, floating platforms, oil drilling rig, pipe-laying vessels and so on.

Technical Parameters

TECHNICAL PARAMETERS
1. SWL SEE LOAD CHART
2. MAX. WORKING RADIUS 2.6-16M
4.

5.		 HOISTING SPEFD 23m/min
HOISTING Hight 30M
HOOK TRAVEL 10m
6. SLEWING SPEFD 1.1r/min
7. SLEWING ANGLE 360°
8. FIRST LUFFING TIME ~90S
9. Second LUFFING TIME ~75S
11. WORKING CONDITION SEE LOAD CHART
TRIM ≤2°
HEEL ≤5°
12. ELEC.Motor Y280S-4-H
POWER RESOURCE AC380V/50HZ
SPEED 1480r/min
13. Deadweight 1300KG
14. design temperature -40*～+35*
15. Oil Flow 110L/min

GA Drawing

Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M

Product Picture

Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M

Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M

Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M

Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M

Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M

Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M

Offshore Marine Knuckle Boom AHC Crane Explosion Proof 8T 16M

FAQ
1. Q: Can this type work in hazardous environments?
A: Sure! We can customize it for you, acid-proof or explosion-proof, no problem with that.
2. Q: Can you provide the serious lifting tools?
A: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. Q: How can we install the crane?
A: Our senior engineer can be on your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q: Safety device
A: Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
