Specifications
Brand Name :
OUCO
Model Number :
OUCO-TB-10T25M
Certification :
CE/ISO9001/ABS/BV/CCS/RMRS/DNV
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Supply Ability :
100 sets per year
Delivery Time :
3 months
Packaging Details :
Shipping Container/Wood Crate/nude
Product Name :
OUCO 10T25M Electric Hydraulic Telescopic Boom Marine Pedestal Crane
Color :
Client Requirement
After-sales Service Provided :
Engineers available to service machinery overseas
Type :
Telescopic Boom
SWL :
10T25M
Elec-Motor Power :
Y160L-4-H
Power :
90 Kw
Power Resource :
AC380V/50HZ
Description

Telescopic Boom Crane hydraulic crane 10T at 25M Electric Hydraulic Crane

Product Description

The telescopic series of cranes offer a diverse product line for application in the Luxury Yacht, Oceanographic, Workboat, Oilfield, Coast Guard or Military industries. These cranes can also be further customized for use in these most demanding of work environments.

All of the cranes in the Telescopic Boom line offer several key features that make them powerful solutions for the marine work environment. The most notable of these features include: Extended boom reach with the dexterity for accurate, safe, and efficient material handling.

Product Feature

1. Running smoothly.

2. Rates of speed can be changed.

3. 360 degrees continually rotary.

4. Both electro hydraulic and manual to control.

5. Operate conveniently.

6. Safety and reliability.

Technical Parameters

SWL 4T@30M&10T25M
MAX WORKING RADIUS 30m
MIN WORKING RADIUS 3m
HOISTING SPEED 0~15m/min
HOISTING HEIGHT 35m
SLEWING SPEED ~0.6r/min
SLEWING ANGLE 360°
LUFFING TIME ~ 90s
WORKING CONDITION

TRIM ≤2°

HEEL ≤5°
ELEC-MOTOR POWER Y160L-4-H
POWER 90kw
Speed 1780r/min
POWER RESOURCE AC440V/60HZ
PROTECT CLASS IP44
INSUKATE CLASS F
WORKING TYPE S1


Genernal Arrangement

Telescopic Boom Crane hydraulic crane 10T at 25M Electric Hydraulic Crane

Product Details

Telescopic Boom Crane hydraulic crane 10T at 25M Electric Hydraulic Crane

Telescopic Boom Crane hydraulic crane 10T at 25M Electric Hydraulic Crane

FAQ

1. Q:Can this type work in hazardous environment?
A:Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Q:Can you provide the serious lifting tools?
A:Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. Q:How can we install the crane?
A:Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q:Safety device
A:Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
