1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area
1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area
1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area
1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area
1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area
1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area
1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area
1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area
Specifications
Brand Name :
OUCO
Model Number :
OUCO-TB-0.98T5M
Certification :
CE/ISO9001/ABS/BV/CCS/RMRS/DNV
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Supply Ability :
50 sets per year
Delivery Time :
45 days
Packaging Details :
Shipping Container/Wood Crate/nude
Color :
custom design
After-sales Service Provided :
engineers available to service machinery overseas
Type :
telescopic and knuckle boom
Insukate Class :
F
Woeking Type :
S1
Description

OUCO 1 Ton Marine Telescopic Crane Hydraulic Marine Deck Crane

Product Description

The KB series, knuckle jib box boom pedestal crane, are a reliable for general cargo handling service and offshore use. On board various ship types and offshore units. Tailor made to your required specifications in different boom length and lifting capacities from 10mt to 2000mt for different sea state working conditions. All KB series cranes can be equipped with different accessories and class certified by all leading classification societies.

Adding various features and options make the foldable knuckle boom cranes a multi-functional tool.

Product Feature

1. Running smoothly.

2. Rates of speed can be changed.

3. 360 degrees continually rotary.

4. Both electro hydraulic and manual to control.

5. Operate conveniently.

6. Safety and reliability.

Technical Parameters

SWL 0.98T5M
Max. Working Radius 5 m
Min. Working Radius 1.1 m
Hoisting Speed 0-12 m/min
Hoisting Height 15 m
Slewing Speed ~0.6 r/min
Slewing Angle 360°
Luffing Time ~20 s
Extension Time ~ 25 s
Working Condition Trim ≤ 2°
Heel ≤ 5°
Power Resource AC380V/50HZ
Power 4.5 kw
Elec-Motor Power Y132ML-4-H


Genernal Arrangement

1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area

Product Details

1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area

1 Ton Marine Hydraulic Boom Crane Telescopic Boom Less Installation Area

FAQ

1. Q:Can this type work in hazardous environment?
A:Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Q:Can you provide the serious lifting tools?
A:Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. Q:How can we install the crane?
A:Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q:Safety device
A:Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
