5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor
5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor
5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor
5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor
5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor
5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor
5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor
5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor
Specifications
Brand Name :
OUCO
Model Number :
OUCO-KB-5T20M
Certification :
CE/ISO9001/ABS/BV/CCS/RMRS/DNV
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Supply Ability :
50 sets per year
Delivery Time :
3 months
Packaging Details :
Shipping Container/Wood Crate/nude
Product Name :
OUCO 5T20M Knuckle boom Hydraulic crane with Pedestal Electrical Motor
Color :
Customer Requirement
After-sales Service Provided :
Engineers available to service machinery overseas
Type :
Telescopic Knuckle Boom
Hoisting Speed :
0-10 m/min
Hoisting Height :
30 m
Slewing Speed :
~0.8 r/min
Slewing Angle :
360°
Description

OUCO 5T20M Knuckle boom Hydraulic crane with Pedestal Electrical Motor

Product Description

Folding crane Knuckle Boom Crane Marine Crane Pedestal crane 5T at 20m working radius. OUCO Marine/Offshore 5T folding crane Knuckle Boom Crane Marine Crane Pedestal crane.

The KB series, knuckle jib box boom pedestal crane, are a reliable for general cargo handling service and offshore use. On board various ship types and offshore units. Tailor made to your required specifications in different boom length and lifting capacities from 10mt to 2000mt for different sea state working conditions. All KB series cranes can be equipped with different accessories and class certified by all leading classification societies.

Adding various features and options make the foldable knuckle boom cranes a multi-functional tool.

Product Feature

1. Running smoothly.

2. Rates of speed can be changed.

3. 360 degrees continually rotary.

4. Both electro hydraulic and manual to control.

5. Operate conveniently.

6. Safety and reliability.

Technical Parameters

SWL 5T20M
Max. Working Radius 20 m
Min. Working Radius 2.5 m
Hoisting Speed 0-10 m/min
Hoisting Height 30 m
Slewing Speed ~0.8 r/min
Slewing Angle 360°
Luffing Time ~120 s
Knuckle Boom Time ~120 s
Extension Time ~ 150 s
Working Condition Trim ≤ 2°
Heel ≤ 5°
Power Resource AC440V/60HZ
Power 55 kw
Elec-Motor Power Y250M-4-H


Genernal Arrangement

5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor

Product Details

5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor

5T 20M Hydraulic Knuckle Crane Custom Color With Pedestal Electrical Motor

FAQ

1. Q:Can this type work in hazardous environment?
A:Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Q:Can you provide the serious lifting tools?
A:Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. Q:How can we install the crane?
A:Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q:Safety device
A:Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
