High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
Specifications
Brand Name :
Achemetal
Model Number :
Customization
Certification :
ISO14001
Place of Origin :
Henan, China
MOQ :
1kg
Price :
$10.00-$70.00
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Kilogram/Kilograms per Month
Packaging Details :
1) inner packed by vacuum plastic bags with lining foam 2) outer packed by cardboard boxes or plywood cases
Sample service :
Accept
La :
0.4~0.7%
Content :
Mo-La alloy
Technique :
CNC,Forged,Sintered
Dimensionst :
3~400mm
Boiling point :
4615℃
Usage :
Thin Film Coating
Description

Product Detail

Product Description

High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm

Molybdenum-lanthanum alloys, also known as high temperature molybdenum, are molybdenum alloys that are doped with rare-earth lanthanum to improve the high temperature properties of molybdenum and other properties. In order to improve the high temperature properties and working life of pure molybdenum used as a high temperature material, molybdenum is doped with lanthanum and other rare earths to increase the recrystallisation temperature of the material from 1000 to 1100°C to 1500 to 1600°C. The tensile strength at 20°C can reach 1400 MPa, which is reflected in the creep resistance of the material during use, thus greatly expanding the range of molybdenum materials used at high temperatures and This greatly extends the range and service life of molybdenum at high temperatures.

 Specification

molybdenum rare earth alloys such as molybdenum-cerium and molybdenum-lanthanum have better high-temperature properties than pure molybdenum, but also better electron-emitting properties, thus gaining application in the electronic information industry. Alloys with a lanthanum oxide content of 0.8% to 1.2% can be produced in bulk in the form of molybdenum-lanthanum alloy sheets, molybdenum-lanthanum alloy rods and various parts with the same dimensions and precision as pure molybdenum.

Elongation of Mo alloys(%)

Alloy 1000℃ 1200℃ 1300℃ 1400℃ 1600℃ 1800℃
MoLa1 13.54³ 18.04³ 2.87 1.59 2.64
MoLa1 13.5 15.4 24.8 4.1 5.7 5
TZM2 9.1 13.8 16.6³ 14.7³ 28.2³

Diameter and Tolerance

diameter(mm) tolerance of diameter length(mm) tolerance of length
16-20 +1.0 300-1500 +2
20-30 +1.5 250-1500 +2
30-45 +1.5 200-1500 +3
45-60 +2.0 250-1300 +3
60-100 +3.0 250-800 +3

Production Process

High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm

Application

High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm

Suitable for producing ion implatation parts
For producing electric light source parts and electric vacuum components
For producing heating elements and refractory parts in high temperature furnaces

Packing & Delivery

High Temperature Molybdenum Alloys Molybdenum Lanthanum Rods 3~400mm
