Specifications
Brand Name :
Achemetal
Model Number :
customized
Certification :
ISO9001
Place of Origin :
Henan,china
MOQ :
1PCS
Price :
$100.00 - $300.00
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000kg per Month
Delivery Time :
30 days
Packaging Details :
Carton or wooden box,packing with Standard wooden case fixed with foam inside, size according to product customization
Material :
Tungsten
Purity :
99.95%
Density :
19.2g/cm³
Dimensions :
User's demand
Shape :
As required
Surface :
Black or machined
working temperature :
Up to 2600℃
Application :
High temperature resistance
Description

Product description

Fasteners of our company are formed by deep-processing high-density large-deformation bars and plates. Without the phenomena of thread falling and corrosion, tungsten screw rods and tungsten nuts have good high-temperature resistance, and can achieve firm connection at high temperature. Meanwhile, our company carries out special treatment on the surfaces of fasteners by polishing and sand blasting treatment, so that the products have uniform surface colors and luster as well as more attractive appearance on the basis of ensuring stable using performance of products. All the products passing the inspection are vacuum-packaged.

Fasteners include screws, nuts, pins, rivets, gaskets, spacing pieces, etc.

Product specification

We have a large number of precision CNC lathes, machining centers, wire-electrode cutting devices and other facilities. We can manufacture screw rods with GB threads, inch threads and US system threads, inner hexagon, outer hexagon, straight slots, cross slots and so on according to customer requirements, and can also process products according to drawings required by customers.

Classification Specification
Screws M3,M4,M5,M6,M8,M10,M16,etc.
Nuts M3,M4,M5,M6,M8,M10,M16,etc.
Pins Processing as required
Rivets Ф1.2,Ф1.5,Ф1.8,Ф2.0,Ф2.5,Ф3
Gaskets Processing as required

Grade Element Composition %
W Al Ca Fe Mg Mo Ni Si
W1 Remainder>99.95% 0.002 0.005 0.005 0.003 0.01 0.003 0.005
C N O
0.008 0.003 0.005

Technological process

Custom Sized  M3 -M16 Tungsten Nuts And Bolts 19.2g/Cm3 High Strength

Product detail

Custom Sized  M3 -M16 Tungsten Nuts And Bolts 19.2g/Cm3 High Strength

Custom Sized  M3 -M16 Tungsten Nuts And Bolts 19.2g/Cm3 High Strength

Custom Sized  M3 -M16 Tungsten Nuts And Bolts 19.2g/Cm3 High Strength

Product application:

Bolts and nuts for sapphire crystal furnaces

Tungsten screws, molybdenum screws, tungsten nuts and molybdenum nuts for high-temperature vacuum furnaces or gas heat preserving furnaces

Fasteners for the monocrystalline silicon industry

Shielding screws for semiconductor and electronic industries

Packaging details:

Packing with moisture-proof paper;
Packing with Kraft paper;
Packing with foam plastics in all sides;
Packing products in standard wooden cases.

Shipping terms :

We could offer shipping by sea ,and shipping by air ,such as Fedex, UPS, TNT, EXW,FOB etc.

Many express companies cooperated with our company for many years , They will provide the lowest freight . And we will compare the offer and choose the best one for you.
