Specifications
Brand Name :
LongJoin
Model Number :
JL-205C
Place of Origin :
China
Price :
negotiable
Packaging Details :
Different packaging methods are adopted according to different modes of transport.
Payment Terms :
Western Union,,T/T
Rated Voltage :
120~277VAC(205C) / 12VDC(205-12D) / 24VDC(205-24D)
Relay :
15A
Operate Levels :
10~20Lx Turn-On / 30~60Lx Turn-Off
IP level :
IP54 / IP65 / IP67
Certifications :
RoHS,UL,CE
Real-world Scenarios :
Airport & Seaport Lighting
Description
Electronic Photocontrol Fail On Surge Arrester Built In Street Garden Passage Doorway Lighting
Product Overview

The JL-205C photocontrol automatically controls street lighting, garden lighting, passage lighting, and doorway lighting based on ambient natural lighting levels.

This product features electronic circuits with phototransistor and includes a built-in surge arrester (MOV). The JL-205C model provides a wide voltage range for applications under various power supplies. A preset 3-20 seconds time-delay prevents redundancy operation due to spotlight or lightning during nighttime.

This product meets ANSI C136.10 requirements with Twist-lock terminals and complies with ANSI/UL773 standards for plug-in, locking type photocontrols for area lighting. JL-205-12D/24D models are available for DC applications.

Product Dimensions
Electronic Photocontrol Fail On Surge Arrester Built In Street Garden Passage Doorway Lighting
Product Features
  • ANSI C136.10 Twist-lock design
  • 3-20 second time delay
  • Built-in surge arrester
  • Fail-on mode operation
  • UV stabilized enclosure
  • IP54/IP65/IP67 protection available
Technical Specifications
Model No. JL-205C JL-205-12D JL-205-24D
Rated Voltage 120~277VAC 12VDC 24VDC
Rated Frequency 50/60Hz - -
Applicable Voltage Range 105~305VAC - -
Relay 15A
Rated Loading 1000W Tungsten, 1800VA Ballast, 8A@120VAC/5A@208-277V e-Ballast 75W Tungsten 75VA Ballast 2A e-Ballast 150W Tungsten 150VA Ballast 2A e-Ballast
Power Consumption 3W@120V - -
Operate Levels 10~20Lx Turn-On / 30~60Lx Turn-Off
Ambient Temperature -40℃ ~ +70℃
Related Humidity 96%
Fail Mode Fail-On
Shell Material Optional Sandwich cover
High Protection Sandwich cover (optional)
IP Level IP54 / IP65 / IP67
Certifications
Electronic Photocontrol Fail On Surge Arrester Built In Street Garden Passage Doorway Lighting
Electronic Photocontrol Fail On Surge Arrester Built In Street Garden Passage Doorway Lighting Electronic Photocontrol Fail On Surge Arrester Built In Street Garden Passage Doorway Lighting
Frequently Asked Questions
What type of control device is this product?
It is an electronic photocontrol for automatic light control.
Does this photocontrol have a built-in surge arrester?
Yes, it has a surge arrester built in for better lightning and surge protection.
What is the fail mode of this electronic photocontrol?
It adopts fail-on mode, ensuring lights stay on in case of failure.
Where can this photocontrol be applied?
It is suitable for street, garden, passage and doorway lighting.
What are the advantages of built-in surge protection?
It improves safety, stability and service life against voltage surges.
