Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell
Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell
Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell
Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell
Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell
Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell
Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell
Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell
Specifications
Brand Name :
KVOU
Model Number :
SBJZ21101A
Certification :
CE/TUV
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, D/P, D/A
Supply Ability :
5000 unit per month
Delivery Time :
7-15working days
Packaging Details :
Wooden case and Carton case
Nominal Voltage :
3.2V
Nominal Capacity :
280Ah
Battery Type :
Lifepo4 Battery Cell
Battery Weight :
5.5KG
Warranty :
3 Years
OEM/ODM :
Available
Battery Shape :
Square
Cooling :
Natural cooling
Description

Prismatic Lithium Ion Battery Cell 3.2V 280Ah For Home Appliances

Our Li-Ion batteries feature an excellent energy density and their high voltage ensures small battery dimensions. They are able to supply stable power with a flat discharge voltage and a high reliability. Last but not least, their low self-discharge is impressive. The usage of our Li-Ion batteries requires a safety unit. Our Li-Ion prismatic cells are particularly designed for POS terminals etc.

Features
Excellent energy density and high voltage ensures small battery dimensions
Stable power supply with a flat discharge voltage
Low impressive self-discharge
The usage of our Li-Ion batteries requires a safety unit
Excellent battery safety on one hand, and superior battery performance on the other.

Items
Specifications
Nominal Voltage
3.2V
Nominal Capacity
280Ah
Standard Charge Current
0.2C-0.5C
Max. Charge Current
1C
Continuous Discharge Current
1C
Peak Discharge Current
2C
Charge Cut-off Voltage
3.9V
Discharge Cut-off Voltage
2V
Inner Resistance
≤ 0.3mΩ (At 0.2C rate, 2.0V cut-off)
Weight
5.5kg
Dimension
Length: 205mm
Width: 175mm
Thickness: 72mm
Operating Temperature
Charging: 0°C ~ 45°C
Discharging: -20°C ~ 55°C
Storage Temperature
optimal store temperature of 23 ± 5°C for long term storage
Life Cycle
≥3500 times (100% DOD till 80% of initial capacity at 0.2C rate, IEC Standard)

Home Appliances Lithium Ion Battery Cell 3.2V 280Ah Lithium Prismatic Cell

FQA:

1. Are Prismatic Lithium batteries any good?
Prismatic cells are mainly used in energy storage systems and electric vehicles. Their larger size makes them bad candidates for smaller devices like e-bikes and cellphones. Therefore, they are better suited for energy-intensive applications.

2. What is the life of prismatic cells?
LFP/G prismatic cell shows ultrahigh longevity of 50,000 cycles reaching 20% of residual capacity with the coulombic efficiency of ∼99.99% and constant ohmic resistance at 2 C cycling. The capacity retention is 80, 30 and 20% after 1,800, 30,000 and 50,000 cycles, respectively.

3. Which lithium battery is best?
Safe, Stable Chemistry. LiFePO4 is the safest lithium battery type. It's the safest of any type, actually. Overall, LifePO4 batteries have the safest lithium chemistry.

4. Is it OK to leave a lithium-ion battery on the charger overnight?

Yes — but there's a caveat. “In general, it is generally safe to do so, but there are a few caveats that should be taken into consideration,” Salvador said. “First and foremost, if you have a newer phone with a lithium-ion battery, charging it overnight could increase its temperature significantly.”
