Specifications
Model Number :
GM50
Place of Origin :
ZHEJIANGNINGBO
MOQ :
1K
Price :
The price ranges from 10 to 50 yuan per unit. The specific model requirements vary
Payment Terms :
T/T
Supply Ability :
100,000 units per month
Delivery Time :
30work days
Packaging Details :
Carton with pallet
Brand Name :
LINO
Certification :
ROHS
VOLTAGE :
6VDC,12VDC,24VDC
Direction of rotation :
CW, CCW
Motor type :
RF520,RF500 ,RF370,RS365,RS385 DC MOTOR
Shaft :
Customizable
Gear ratio :
widely range of ratio
Description

DC GEAR MOTOR GM50

Products' type: DC geared motor

85g DC Gear Motor 24 Volt GM50 For Electronic Lock , Optical Equipment
Model: GM50
Sort: Pear shape DC geared motor
Typical applications: Coffee machine, communications-equipment, ACU-RITE,induced garbage can, electronic lock, optical equipment, medical instrumentation, office equipment, household appliances,etc…
Weight 85g (approx)

MODEL VOLTAGE AT NO LOAD AT MAXIMUM EFFICIENCY AT STALL
SPEED CURRENT SPEED CURRENT TORQUE TORQUE CURRENT
VDC RPM A RPM A mN.m kg.cm mN.m kg.cm A
GM50600-360 24 11.5 0.095 9.4 0.22 1842.4 18.800 10094 103.000 0.78
Base motor option RS360,RS365,RF370,RS380,RS385,RS390,RS395,RF500,RF520,RF500
Gear ratio option

a: 6.25,7.5, 8.33, 11.25, 12.5, 14.1, 15, 17.6, 20, 25, 30, 33.3, 37.5, 41.6, 45, 50,56.25, 60, 62.5, 66.6, 75, 83.3, 84.375, 90, 93.75, 100, 112.5, 120, 125, 133.33, 135, 150, 166.6, 168.75, 180, 187.5, 200, 208.3, 225, 240, 250, 266.67, 270, 281.25, 300, 312.5, 333.3, 337.5, 360, 375, 400, 405, 416.6, 421.875, 450, 468.75, 500, 506.25, 540, 562.5, 600, 625, 666.67, 675, 703.125, 750, 833.3, 843.75, 900, 937.5, 1000, 1041.6, 1125, 1250, 1406.25, 1500, 1562.5, 1666.6, 1875, 2083.3, 2343.75, 2500, 3125)

b:(500, 666.67, 694.4, 833.333, 925.925, 1111.1, 1125, 1234.57, 1388.9, 1500, 1851.85, 2000, 2083.3, 2250, 2314.8, 2500, 2666.67, 2777.78, 3000, 3086.4, 3125, 3333.3, 3703.7, 3750, 4000, 4166.67, 4444.4, 4500, 4938.27, 5000, 5208.3, 5555.556, 6000, 6250, 6666.67, 6750, 6944.4, 7407.4, 7500, 8000, 8333.3, 9000, 9259.26, 10000, 10125, 10416.67, 10666.67, 11111.1, 11250, 12000, 12345.68, 12500, 13333.3, 13500, 13888.89, 15000, 16000, 16666.67, 16875, 17361.1, 17777.78, 18000, 18518.5, 18750, 20000, 20250, 20833.3, 22500, 23148.15, 24000, 25000, 26666.67, 27000, 27777.78, 28125, 30000, 30864.2, 33333.3, 33750, 34722.2, 36000, 37500, 40000, 40500, 44444.4, 45000, 46296.3, 46875, 50000, 54000, 56250, 57870.37, 60000, 62500, 66666.67, 67500, 75000, 77160.5, 83333.3, 90000, 93750, 100000, 111111.1, 112500, 125000, 150000, 156250, 166666.67, 187500, 208333.3, 250000, 277777.78, 312500, 416666.67, 520833.3, 694444.4)
Note The specifications and output shaft can be changed as customer's request.
Packing detail Carton, Size: 38X35.5X34CM;100pcs/carton; G.W:11Kg.
