Specifications
Brand Name :
LINO
Model Number :
GMS4967
Certification :
ROHS
Place of Origin :
ZHEJIANGNINGBO
MOQ :
1K
Price :
The price ranges from 10 to 20 yuan per unit. The specific model requirements vary
Payment Terms :
T/T
Supply Ability :
100,000 units per month
Delivery Time :
30work days
Packaging Details :
Carton with pallet
VOLTAGE :
3VDC,4.5VDC,6VDC
Direction of rotation :
ACTUATOR
Motor :
RF300
Noise :
<45dB
Typical application :
Thermostatic valve
Description

DC GEAR MOTOR GMS4967

Products' type: DC geared motor

LINO RF300 High Torque Dc Motors 3VDC 4.5VDC 6VDC Lino Motors GMS4967
Model: GMS4967
Sort: DC geared motor
Typical applications: Valve,for heater valve
Weight 50g (approx)

MODEL VOLTAGE AT NO LOAD AT MAXIMUM EFFICIENCY AT STALL
SPEED CURRENT SPEED CURRENT TORQUE TORQUE CURRENT
VDC RPM A RPM A mN.m kg.cm mN.m kg.cm A
GMS4967496-300 3 4 0.024 2.6 0.046 107.8 1.100 313.6 3.200 0.09
Base motor option RF300
Gear ratio option 496
Note The specifications and output shaft can be changed as customer's request.
Packing detail Carton, Size:49.5X32X28CM;200pcs/carton; G.W:11Kg.
