CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
Specifications
Brand Name :
CHE
Model Number :
CKK40
Certification :
RoSH, REACH, ISO9001:2015
Place of Origin :
China
MOQ :
1 unit
Supply Ability :
As pre your request
Delivery Time :
3~7 working days for sample
Packaging Details :
Cartoons with plastic bag and foam
Payment Terms :
D/P, T/T
Material :
Aluminum Alloy
Core Components :
Motor+ ball screw+linear guide
Precision :
20~25μm(≤300mm)
Type :
CKK Linear Stage
Length :
100mm, 150mm, 200mm
Loads :
up to 250 kg
Thrust :
150~600N
Description

CKK40 Linear Stage Linear Module With Ball Screw

Accurate positioning: since the friction way of the linear module is rolling friction, not only the friction coefficient is reduced to 1/50 of the sliding guide, but the gap between the dynamic friction force and the static friction force is also small. Therefore, when the sliding table is running, there will be no slippage, and the positioning accuracy of μm level can be achieved.

Ball screw linear stage: The kk series is designed with many standard features and options that make the design incredibly flexible and allow it to be easily tailored to a specific application. Travels range from 36 to 136 mm with speeds up to 300 mm/s.

High interchangeability: the linear slide rail is interchangeable, and the slider and slide rail can be replaced respectively. Even linear slides, the machine can regain high-precision guidance

Multi-functional design: integrating the ball screw for driving and the U-shaped track for guiding, in addition to providing precise linear motion, it can also be matched with multi-functional accessories. It is very convenient to import multi-purpose application design, and can also meet the needs of high-precision linear transmission.

CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw

CKK40 Linear System Dimensions

CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw

Rail Length

L2(mm)

Total Length

L1(mm)

 Maxium Effective Stroke G(mm) n(mm) Weight
A1 Slider A2 Slider A1 A2
100 159 36 - 20 2 0.48 -
150 209 86 34 15 3 0.6 0.67
200 259 136 84 40 3 0.72 0.79

Linear Motion Module Details>>>>>>>>>>>>

CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw

CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw

Workshop >>>>>>>>>>>>

CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw

CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
CKK40 Aluminum Alloy Linear Stage , Linear Module With Ball Screw
