3.7V 280mAh Lipo Battery 500 Cycles 1C Discharge OiD651533-280
3.7V 280mAh Lipo Battery 500 Cycles 1C Discharge OiD651533-280
3.7V 280mAh Lipo Battery 500 Cycles 1C Discharge OiD651533-280
3.7V 280mAh Lipo Battery 500 Cycles 1C Discharge OiD651533-280
Specifications
Brand Name :
OiD
Model Number :
OiD651533-280
Certification :
Compliant with IEC 62133，UN38.3，REACH
Place of Origin :
China
MOQ :
100pcs
Price :
$0.5 ~ $100.0 / pcs
Delivery Time :
3 ~ 7 days for storage
Payment Terms :
TT,L/C,Western Union
Name :
3.7 V Lipo Battery
Battery Type :
3.7V, 280mAh Rechargeable
ODM :
Free custom design for packs
High Energy Density :
250-300Wh/kg
Superior Cold Weather Performance :
Reliable in Extreme Cold (-20°C to 60°C)
Cycle Life :
500+ cycles
Charging/ Discharging :
1C/ 1C
Flexible Form Factor :
Thin, Customizable Pouch Design Lithium Ion Battery
Description
3.7V 280mAh Lipo Battery 500 Cycles 1C Discharge OiD651533-280

OiD651533-280 Lithium Polymer Battery 3.7V 280mAh 1C Discharge 500 Cycles

Product Name

OiD651533-280 Lithium Polymer Battery

Advantages

  • High energy density
  • Long cycle life
  • Lightweight and compact design
  • Safe and reliable performance

Specifications

Parameter

Value

Nominal Voltage

3.7V

Minimum Capacity

275mAh (0.2C discharge)

Typical Capacity

280mAh (0.2C discharge)

Charging Voltage

4.2V

Discharging Cut-off Voltage

3.0V

Standard Charging

0.2C/4.2V

Max Charging

1.0C/4.2V

Standard Discharging

0.2C/3.0V

Max Discharging

1.0C/3.0V

Weight

Approx. 5.0g

Shipment Voltage

3.90±0.05V

Battery Pack Impedance

≤300mΩ

Terminal Type

Tab

Terminal Material

Nickel

Cycle Life

Condition

Cycles

Capacity Retention

0.2C Charge/Discharge at 23±2℃

500

≥80%

Discharge Curve

3.7V 280mAh Lipo Battery 500 Cycles 1C Discharge OiD651533-280

Operating Temperature Range

Condition

Temperature Range

Charging

0℃ ~ 45℃

Max Charging Current (0℃ ~ 10℃)

0.2C max

Max Charging Current (10℃ ~ 20℃)

0.5C max

Max Charging Current (20℃ ~ 45℃)

1.0C max

Discharging

-20℃ ~ 60℃

Max Discharging Current (-20℃ ~ 0℃)

0.2C max

Max Discharging Current (0℃ ~ 25℃)

0.5C max

Max Discharging Current (25℃ ~ 60℃)

1.0C max

Storage (50% SOC)

-10℃ ~ 25℃ (12 months, ≥85%)

Storage (50% SOC)

-10℃ ~ 45℃ (6 months, ≥85%)

Storage (50% SOC)

-10℃ ~ 55℃ (1 month, ≥90%)

Certifications

  • RoHS compliant
  • UL1642 certified
  • IEC/EN61960 compliant
  • GB/T 18287-2013 compliant

Key Features

  • High discharge rate capability
  • Excellent low-temperature performance
  • Built-in protection circuit for overcharge, over-discharge, and short-circuit protection
  • Environmentally friendly and recyclable

Applications

  • Wearable devices
  • Medical devices
  • IoT devices
  • Portable electronics
  • Smart home devices

3.7V 280mAh Lipo Battery 500 Cycles 1C Discharge OiD651533-280

Usage Warnings & Precautions

  • Do not short-circuit the battery terminals.
  • Avoid exposing the battery to high temperatures or direct sunlight.
  • Use only the specified charger for charging.
  • Do not disassemble or modify the battery.
  • Keep the battery away from children and pets.

Storage Guidelines

  • Store the battery at 20±5℃ for optimal performance.
  • If storing for more than 3 months, charge the battery to 60% capacity every 3 months.
  • Avoid storing the battery in humid or high-temperature environments.

Warranty & Disclaimer

  • 12-month warranty from the date of shipment.
  • The warranty does not cover damage caused by improper use, mishandling, or unauthorized modifications.
  • The manufacturer is not responsible for any accidents or damages resulting from the misuse of the battery.
