7.4V 230mAh Lithium Ion Battery 300 Cycles 1.5C Discharge
7.4V 230mAh Lithium Ion Battery 300 Cycles 1.5C Discharge
7.4V 230mAh Lithium Ion Battery 300 Cycles 1.5C Discharge
7.4V 230mAh Lithium Ion Battery 300 Cycles 1.5C Discharge
Specifications
Brand Name :
OiD
Model Number :
OiD502023-2S-230
Certification :
Compliant with IEC 62133，UN38.3，REACH
Place of Origin :
China
MOQ :
100pcs
Price :
$0.5 ~ $100.0 / pcs
Delivery Time :
3 ~ 7 days for storage
Payment Terms :
TT,L/C,Western Union
Name :
Lithium Ion Battery
Battery Type :
7.4V, 230mAh Rechargeable
ODM :
Free custom design for packs
High Energy Density :
250-300Wh/kg
Superior Cold Weather Performance :
Reliable in Extreme Cold (-20°C to 60°C)
Cycle Life :
300+ cycles
Charging/ Discharging :
1C/ 1.5C
Flexible Form Factor :
Thin, Customizable Pouch Design Lithium Ion Battery
Description

7.4V 230mAh Lithium Ion Battery 300 Cycles 1.5C Discharge

OiD502023-2S-230 7.4V 230mAh 1.5C Discharge 300 Cycles Lithium Polymer Battery

Product Name:

OiD502023-2S-230 Lithium Polymer Battery

Advantages:

  • High energy density
  • Long cycle life
  • Lightweight and compact design
  • Safe and reliable performance

Specifications:

Parameter

Value

Nominal Voltage

7.4V

Minimum Capacity

200mAh (0.2C discharge)

Typical Capacity

230mAh (0.2C discharge)

Charging Voltage

8.4V

Discharging Cut-off Voltage

6.0V

Standard Charging

0.2C/8.4V

Max Charging

1.0C/8.4V

Standard Discharging

0.2C/6.0V

Max Discharging

1.5C/6.0V

Weight

Approx. 9.0g

Shipment Voltage

7.80V±0.1V

Battery Pack Impedance

≤530mΩ

Cycle Life:

Condition

Cycles

Capacity Retention

0.2C Charge/Discharge at 23±2℃

300

≥80%

Discharge Curve:

7.4V 230mAh Lithium Ion Battery 300 Cycles 1.5C Discharge

Operating Temperature Range:

Condition

Temperature Range

Charging

0℃ ~ 45℃

Discharging

-20℃ ~ 60℃

Storage (50% SOC)

-10℃ ~ 25℃ (12 months, ≥85%)

Storage (50% SOC)

-10℃ ~ 45℃ (6 months, ≥85%)

Storage (50% SOC)

-10℃ ~ 55℃ (1 month, ≥90%)

Recommended Storage Temperature

20±5℃

Certifications:

  • GB/T 18287-2013
  • IEC/EN61960
  • UL1642

Key Features:

  • Overcharge, over-discharge, and short-circuit protection
  • High-temperature and low-temperature performance
  • RoHS compliant

Applications:

  • Portable electronic devices
  • Medical devices
  • IoT devices
  • Wearable technology

7.4V 230mAh Lithium Ion Battery 300 Cycles 1.5C Discharge

Usage Warnings & Precautions:

  • Use the original battery charger
  • Avoid short-circuiting the battery
  • Do not expose to high temperatures or pressure
  • Stop using if any abnormalities are observed

Storage Guidelines:

  • Store at 20±5℃ for optimal performance
  • Charge to 60% capacity if not used for 3 months
  • Remove from devices when not in use

Warranty & Disclaimer:

  • 12-month warranty from the shipment date
  • Proper handling and usage are required
  • Manufacturer is not responsible for accidents caused by improper use
