3.7V 200mAh Lithium Polymer Battery 300 Cycles 1C Discharge
3.7V 200mAh Lithium Polymer Battery 300 Cycles 1C Discharge
3.7V 200mAh Lithium Polymer Battery 300 Cycles 1C Discharge
3.7V 200mAh Lithium Polymer Battery 300 Cycles 1C Discharge
Specifications
Brand Name :
OiD
Model Number :
OiD481240-200
Certification :
Complies with GB/T 18287-2013, IEC/EN61960, and UL1642 standards
Place of Origin :
China
MOQ :
100pcs
Price :
$0.5 ~ $100.0 / pcs
Delivery Time :
3 ~ 7 days for storage
Payment Terms :
TT,L/C,Western Union
Name :
3.7 V 200mah Lithium Polymer Battery
Battery Type :
3.7V, 200mAh Rechargeable
ODM :
Free custom design for packs
High Energy Density :
250-300Wh/kg
Superior Cold Weather Performance :
Reliable in Extreme Cold (-20°C to 60°C)
Cycle Life :
300+ cycles
Charging/ Discharging :
1C/ 1C
Flexible Form Factor :
Thin, Customizable Pouch Design Lithium Ion Battery
Description

OiD481240-200 3.7V 200mAh 1C Discharge 300 Cycles Lithium Polymer Battery

Product Name:

OiD481240-200 Lithium Polymer Battery

Advantages:

  • High energy density and lightweight design.
  • Long cycle life with up to 300 charge/discharge cycles.
  • Safe and reliable with built-in protection circuits.
  • Wide operating temperature range for versatile applications.

Specifications:

Parameter

Value

Model

OiD481240-200

Nominal Voltage

3.7V

Minimum Capacity

185mAh (0.2C discharge)

Typical Capacity

200mAh (0.2C discharge)

Charging Limit Voltage

4.2V

Discharge Cut-off Voltage

2.7V

Standard Charging Current

0.2C / 4.2V

Max Charging Current

1.0C / 4.2V (0°C~5°C: 0.5C max, 5°C~20°C: 0.8C max, 20°C~45°C: 1.0C max)

Standard Discharging Current

0.2C / 3.0V

Max Discharging Current

1.0C / 3.0V (-20°C~0°C: 0.2C max, 0°C~25°C: 0.5C max, 25°C~50°C: 1.0C max)

Weight

Approx. 4.5g

Battery Pack Impedance

≤300mΩ

Cycle Life:

Cycle Condition

Cycle Life

Capacity Retention

0.2C Charge/Discharge

300 Cycles

≥80%

Discharge Curve:

3.7V 200mAh Lithium Polymer Battery 300 Cycles 1C Discharge

Operating Temperature Range:

Condition

Temperature Range

Performance

Charging

0°C ~ 45°C

Max charging current varies with temperature (0°C~5°C: 0.5C, 5°C~20°C: 0.8C, 20°C~45°C: 1.0C)

Discharging

-20°C ~ 50°C

Max discharging current varies with temperature (-20°C~0°C: 0.2C, 0°C~25°C: 0.5C, 25°C~50°C: 1.0C)

Storage

-10°C ~ 25°C

12 months, ≥85% recoverable capacity

-10°C ~ 45°C

6 months, ≥85% recoverable capacity

-10°C ~ 50°C

1 month, ≥90% recoverable capacity

Certifications:

  • Complies with GB/T 18287-2013, IEC/EN61960, and UL1642 standards.

Key Features:

  • High discharge rate up to 1C.
  • Built-in NTC thermistor for temperature monitoring.
  • Low self-discharge rate for long storage life.
  • RoHS compliant and environmentally friendly.

Applications:

  • Wearable devices
  • IoT devices
  • Medical devices
  • Portable electronics

3.7V 200mAh Lithium Polymer Battery 300 Cycles 1C Discharge

Usage Warnings & Precautions:

  • Do not short-circuit the battery terminals.
  • Avoid exposing the battery to high temperatures or direct sunlight.
  • Use only the specified charger for charging.
  • Do not disassemble or modify the battery.
  • In case of leakage, odor, or deformation, stop using the battery immediately.

Storage Guidelines:

  • Store the battery at 20±5°C for optimal performance.
  • If storing for more than 3 months, charge the battery to 60% capacity every 3 months.
  • Avoid storing the battery in humid or high-temperature environments.

Warranty & Disclaimer:

  • 12-month warranty from the date of shipment.
