3.7V 220mAh Lithium Polymer Battery 300 Cycles 1C Discharge
3.7V 220mAh Lithium Polymer Battery 300 Cycles 1C Discharge
3.7V 220mAh Lithium Polymer Battery 300 Cycles 1C Discharge
3.7V 220mAh Lithium Polymer Battery 300 Cycles 1C Discharge
Specifications
Brand Name :
OiD
Model Number :
OiD532025C-220
Certification :
Compliant with IEC 62133，UN38.3，REACH
Place of Origin :
China
MOQ :
100pcs
Price :
$0.5 ~ $100.0 / pcs
Delivery Time :
3 ~ 7 days for storage
Payment Terms :
TT,L/C,Western Union
Name :
3.7 V 220mah Lipo Battery
Battery Type :
3.7V, 220mAh Rechargeable
ODM :
Free custom design for packs
High Energy Density :
250-300Wh/kg
Superior Cold Weather Performance :
Reliable in Extreme Cold (-20°C to 60°C)
Cycle Life :
300+ cycles
Charging/ Discharging :
1C/ 2C
Flexible Form Factor :
Thin, Customizable Pouch Design Lithium Ion Battery
Description
3.7V 220mAh Lithium Polymer Battery 300 Cycles 1C Discharge

OiD532025C-220 3.7V 220mAh 1C Discharge 300 Cycles Lithium Polymer Battery

Product Name:
OiD532025C-220 Lithium Polymer Battery

Advantages:

  • High energy density and lightweight design
  • Long cycle life with stable performance
  • Safe and reliable with built-in protection circuits
  • Supports multiple terminal options for versatile applications

Specifications:

Parameter

Value

Nominal Voltage

3.7V

Minimum Capacity

200mAh (0.2C discharge)

Typical Capacity

220mAh (0.2C discharge)

Charging Voltage

4.2V

Discharge Cut-off Voltage

3.0V

Standard Charge

0.2C/4.2V

Max Charge Current

1.0C/4.2V

Standard Discharge

0.2C/3.0V

Max Discharge Current

1.0C/3.0V

Weight

Approx. 6.5g

Shipment Voltage

3.90±0.05V

Battery Impedance

≤260mΩ

Supported Terminals

JST-PH2.0, JST-XH, Custom Options

Cycle Life:

Condition

Performance

300 Cycles at 0.2C

Capacity ≥80%

Discharge Curve:
3.7V 220mAh Lithium Polymer Battery 300 Cycles 1C Discharge

Operating Temperature Range:

Condition

Temperature Range

Charging

0°C to 45°C

Discharging

-20°C to 55°C

Storage (50% SOC)

-10°C to 25°C (12 months, ≥85%)

Storage (50% SOC)

-10°C to 45°C (6 months, ≥85%)

Storage (50% SOC)

-10°C to 55°C (1 month, ≥90%)

Certifications:
Complies with GB/T 18287-2013, IEC/EN61960, and UL1642 standards.

Key Features:

  • Overcharge, over-discharge, and short-circuit protection
  • High-temperature and low-temperature performance
  • RoHS compliant
  • Supports JST-PH2.0, JST-XH, and custom terminal options

Applications:

  • Portable electronic devices
  • Wearable technology
  • Medical devices
  • IoT devices

3.7V 220mAh Lithium Polymer Battery 300 Cycles 1C Discharge

Usage Warnings & Precautions:

  • Avoid overcharging or over-discharging.
  • Do not short-circuit the battery terminals.
  • Use only with compatible chargers.
  • Keep away from high temperatures and direct sunlight.

Storage Guidelines:

  • Store at 20±5°C for optimal performance.
  • Maintain 50% SOC for long-term storage.
  • Avoid storing in humid or extreme temperature environments.

Warranty & Disclaimer:
This product is covered by a limited warranty against manufacturing defects. Misuse, improper handling, or unauthorized modifications void the warranty. The manufacturer is not liable for damages arising from improper use.
