36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
Specifications
Brand Name :
OiD
Model Number :
OID1188188SS36AH
Certification :
IEC 62133,UN38.3, MSDS
Place of Origin :
China
MOQ :
1pcs
Price :
$0.5 ~ $200.0 / pcs
Payment Terms :
TT,L/C,Western Union
Supply Ability :
1000000
Delivery Time :
3 ~ 30 days for storage
Packaging Details :
Carton
Name :
Semi-Solid State Li-Po Battery Cell
ODM :
Free custom design for packs
Capacity :
36000mAh
Battery Type :
3.6V 30000mAh Rechargeable
Cycle Life :
500+ cycles
Charging/ Discharging :
2C/15C
Operating Temperature :
-20°C to +55°C
Weight/ size :
400g/11 × 88 × 188 mm
Description
36Ah Capacity Fast-Charge 2C 15C Discharge Semi-Solid Li-ion Drone Battery for UAV Applications
36Ah Fast-Charge Drone Battery Pack Cell | 3.6V Semi-Solid Li-ion UAV Battery
The OID1188188SS36AH is a high-capacity polymer lithium-ion battery cell designed for professional drone battery pack systems and high-power UAV applications. With fast charging capability up to 2C, high discharge performance, and low internal resistance, this battery provides stable power output for long-endurance drone operations and demanding aerial equipment.

Key Features
  • High capacity 36Ah lithium battery cell
  • Fast charge up to 2C for rapid deployment
  • High discharge capability (15C pulse) for UAV power systems
  • Ultra-low internal resistance ≤1mΩ
  • Wide operating temperature range
  • Reliable ≥500 cycle life
  • Designed for professional Drone Battery Pack integration

Main Electrical Specifications
Item Specification
Model OID1188188SS36AH
Nominal Capacity 36.0Ah
Minimum Capacity ≥35.3Ah
Nominal Voltage 3.6V
Charge Cut-off Voltage 4.2V
Discharge Cut-off Voltage 2.5V
Internal Resistance ≤1mΩ
Weight 400 ±20 g
Testing conditions: 25 ±2℃, humidity 15-80%RH

Charging Specifications
Fast Charge
Temperature Charge Current
0-20℃ 18A (0.5C)
20-45℃ 72A (2C)
Standard Charge
18A (0.5C) constant current / constant voltage method. CC-CV charge to 4.2V, cut-off current 0.05C.

Discharge Performance
Discharge Type Current
Maximum Pulse Discharge 540A (15C)
Maximum Continuous Discharge 180A (5C)
Standard Discharge 18A (0.5C)
This high-current capability makes the cell suitable for high-power drone propulsion systems.

Operating Temperature Range
Mode Temperature
Charging 10℃ ~ +45℃
Discharging -20℃ ~ +55℃
This wide temperature range ensures reliable performance in outdoor UAV environments.

Physical Dimensions
Parameter Size
Thickness ≤11.1 mm
Width ≤88.0 mm
Length ≤188.0 mm
Tab specifications:
- Tab width: 30 ±0.1mm
- Tab center distance: 41 ±1.5mm

Electrical Performance Testing
Internal Resistance
≤1mΩ measured using AC impedance method after standard charge.
Initial Capacity
≥35.3Ah measured using standard discharge testing.
Temperature Discharge Characteristics
Temperature Capacity
55℃ ≥95%
25℃ ≥100%
-20℃ ≥60%

Cycle Life
Under standard testing conditions:
- Charge: 0.5C to 4.2V
- Discharge: 1C to 2.75V

After 500 cycles, remaining capacity ≥80% of initial capacity.

Storage Performance
Normal Storage (25℃)
- Retained capacity ≥85%
- Recovered capacity ≥90%
High Temperature Storage (55℃)
- Retained capacity ≥60%
- Recovered capacity ≥80%

Mechanical Reliability Tests
Vibration Test
Frequency 10-55Hz across X/Y/Z directions.
Result: No leakage, No explosion, No fire
Drop Test
1m drop onto concrete surface.
Result: No leakage, No explosion, No fire

Storage Conditions
Recommended storage environment:
Temperature: -20℃ ~ +45℃
Relative humidity: ≤75%

For long-term storage:
Maintain battery voltage between 3.6V - 3.9V and perform periodic activation maintenance.

Safety Precautions
To ensure safe operation:
- Do not overcharge or over-discharge the battery
- Do not short-circuit terminals
- Do not disassemble the battery
- Do not expose the battery to fire or heat sources
- Do not immerse in water
- Use a dedicated lithium battery charger

Failure to follow safety guidelines may cause overheating, smoke, deformation, or fire.

Typical Applications
This battery cell is designed for high-power energy systems such as:
- Drone Battery Pack (UAV battery systems)
- Industrial UAV power modules
- High-power robotics energy systems
- Portable high-capacity power systems

Warranty
Warranty period: 6 months from shipment date.
The manufacturer will replace batteries with verified quality issues within the warranty period.
