Specifications
Brand Name :
Leomed
Productn Name :
PEEK
Color :
Natural/White/Yellow/Red
Density(g/cm3) :
1.32/1.48/1.51/1.35
Bending Strength(MPa) :
163/152/154/158
Bending ModulusBending ModulusBending Modulus(GPa) :
4/5.3/5.6/4.8
Bending Modulus(KJ/m2) :
199/145/162/176
Description

PEEK Dental Discs 160MPa+ Strength, Zirkonzahn & Amann Girrbach Compatible CAD/CAM

Medical-Grade PEEK Dental Discs
Engineered as the ultimate bone-mimetic solution for permanent implant prosthetics, these semi-crystalline PEEK discs deliver revolutionary biomechanical performance. With an elastic modulus (4-5.6 GPa) mirroring cortical bone and flexural strength exceeding 160MPa, they eliminate stress-shielding risks while enabling precision CAD/CAM fabrication at 260°C.

Biomechanical Superiority

  • Stress-Shielding Elimination – 4.0-5.6 GPa modulus matches human bone for load distribution

  • Fatigue-Resistant Architecture – >160MPa flexural strength supports multi-unit bridges

  • Bioinert Certification – ISO 10993-compliant surface inhibits bacterial colonization

  • Imaging Compatibility – Zero CT/MRI artifacts for accurate diagnostics

Clinical Advantage Matrix

Property PEEK Discs Titanium PMMA
Elastic Modulus (GPa) 4.0-5.6 110-120 2.0-3.0
Density (g/cm³) 1.32-1.51 4.4-4.5 1.15-1.19
Allergy Incidence 0% >8% <0.1%
Aesthetic Adaptability Tintable (★★★★☆) Non-adaptable High (★★★★★)

Precision Fabrication Protocol

Tooling Requirements

  • Diamond-coated carbide burs

  • 18,000-25,000 RPM spindle speed

  • ≥0.75 MPa vacuum pressure

Post-Processing

  1. Sandblasting – 50μm alumina oxide

  2. Staining – PEEK-specific dyes (80°C/10min)

Clinical Applications

  • Healing Abutments – 37% ↑ osteoblast proliferation vs titanium

  • Removable Dentures – 60% lighter than cobalt-chrome

  • Surgical Guides – Withstands 200+ autoclave cycles (134°C)

Product Specifications

Grade Density (g/cm³) Flex Strength (MPa) Modulus (GPa)
Natural 1.32 163 4.0
White 1.48 152 5.3
Yellow 1.51 154 5.6
Red 1.35 158 4.8
