Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle
Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle
Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle
Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle
Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle
Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle
Specifications
Brand Name :
LEOTECH
Model Number :
LMW-5
Certification :
IOS CE
Place of Origin :
Chongqing, China
MOQ :
1 set
Price :
$17000/sets
Product Name :
LMW-5 Milling Machine
Material :
Zirconia, PMMA, Wax, Glass Ceramic
Usage :
Dental Lab, Jewelry Making, Prototype Processing
Feature :
5-Axis Control, Wet & Dry Milling
Function :
Automatic Tool Change (27 tools)
Tool Change :
Automatic 10 Tools
Spindle Speed :
60,000 RPM
Power :
2.5 KW
Weight :
390 kg
Description
Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle

The LMW-5 is a fully functional 5-axis milling machine designed for precision processing of a wide range of materials including zirconia, PMMA, wax, and glass ceramics. It supports both wet and dry milling modes, making it versatile for various industrial applications such as dental labs and prototype development. Equipped with a high-power 2.5KW water-cooled spindle running at 60,000 RPM, it ensures efficient and precise cutting. The automatic tool changer with 27 positions enhances productivity by reducing downtime.

Key Features:
  • 5-axis simultaneous control for complex geometries
  • Compatible with all mainstream CAM software
  • Industrial-grade automatic calibration (error ±0.05mm)
  • Integrated mineral casting for long-term stability
  • Half-open blank holder for easy material handling
Specifications:
  • Processing Range: X=305mm, Y=165mm, Z=115mm
  • Axis Rotation: A=360°, B=±30°
  • Power Supply: AC 220V, 50/60Hz
  • Dimensions: 685×770×1700mm

90 Degree Processing

Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle

Industrial-grade automatic calibration (error ±0.05mm)

Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle

Integrated Ineral Casting Long-term Accurate and Stable

Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle

Hign Power Spindle

Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle
Structure Parameter
Number of axes
Millable material Zirconia/PMMA/Wax/Glass Ceramic/Ti/PEEK/Cpcr
Processing method Dry/Wet Milling
Dimension 685X770X1700mm
Weight 390kgs
Automatic tool change quantity 27

Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle


Industrial 5-Axis Wet Dry Milling Machine LMW-5 For Zirconia PMMA Ceramic with 60,000RPM Spindle

Input
Power Supply Single-phase AC 220V 50/60Hz voltage
Power 3.7kw
Air supply pressure 6 Bar
Spindle
Power AC 2.5kw
Cooling method Water cooling
Speed 60,000 rpm
Collet Φ6 mm
Route
X,Y,Z axis 305X165X115mm
A,B axis A:306° B:±30°
