Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
Specifications
Brand Name :
Leenz
Model Number :
LZANT-12230-A
Certification :
RoHs
Place of Origin :
China
MOQ :
10
Payment Terms :
T/T
Supply Ability :
500 per day
Delivery Time :
15 days
Frequency :
3300-3800MHz
VSWR :
<2.0
Peak Gain :
11dBi
Impedance :
50
Description

1. Specification

A. Electrical Characteristics
Frequency 3300-3800MHz
S.W.R. <= 2.0
Antenna Gain 11dBi
Polarization V
Horizontal Beamwidth 45±5°
Vertical Beamwidth 40±5°
F/B >27dB
Impedance 50Ohm
Max. Power 50W
B. Material & Mechanical Characteristics
Connector Type LMR240=2m, N-J
Dimension

260*260*35mm
Radome material ABS
Weight 0.6Kg
C. Environmental
Operation Temperature - 40 ˚C ~ + 85 ˚C
Storage Temperature - 40 ˚C ~ + 85 ˚C
Operation Humidity ＜95%
Rated Wind Velocity 36.9m/s

2. Antenna - S Parameter Test Data
2.1 VSWR
Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm

2.2 Total Efficiency & Gain:

Frequency(MHz)

Gain(dBi)

3300

10.0

3350

10.3

3400

10.4

3450

10.4

3500

10.0

3550

10.0

3600

10.9

3650

11.3

3700

11.5

3750

11.4

3800

11.6

2.3 Radiation Pattern

Port1 2D-Horizontal 2D-Vertical Horizontal & Vertical
3300MHz Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
3550MHz Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
3800MHz Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm Directional 5g Antenna 3300 - 3800 MHz, 3.3 - 3.8 GHz, 11dBi single-polarization directional antenna, base station antenna, 186 x 186 x 28 mm
