IP31 SMD1010 P1.56 Small Pitch LED Display 400X300mm Cabinet
IP31 SMD1010 P1.56 Small Pitch LED Display 400X300mm Cabinet
IP31 SMD1010 P1.56 Small Pitch LED Display 400X300mm Cabinet
IP31 SMD1010 P1.56 Small Pitch LED Display 400X300mm Cabinet
Specifications
Brand Name :
Shenzhen LED World
Model Number :
LW-VI 1.56
Certification :
CE,RoHS,FCC
Place of Origin :
China
MOQ :
1 square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5,00 square meters per month
Delivery Time :
15-22 working days after received your payment
Packaging Details :
Carton/Plywood case/Flight case etc.
Life Time :
>50000h
Cabinet weight :
5Kg
Max.power(W / m2) :
1200
Average.power(W / m2) :
400
Brightness( Nits) :
800
Voltage :
110/240V
Drive Method :
1/32
LED Type :
SMD1010
Description

Small Pitch LED Display P1.56 400 X 300 mm Cabinet Full-Color Aluminum

P1.56 HD LED display/video wall Features:

  1. High precision;
  2. Seamless splicing, High grayscale, good Performance;
  3. Fanless design;
  4. Large view angle;
  5. The most effective solution for indoor HD billboard;
  6. Hd display, the picture is exquisite;
  7. With a small volume, lightweight;
  8. Product splicing is good, there is no gap, the picture shows smooth and great results;
  9. The screen body is very energy efficient, can save 66% of the power consumption;

P1.56 HD LED video wall Parameter:

Item Parameters UHD LED Display Series
Module Pixel Pitch (mm) 1.56mm
Pixel density(pix/m2) 409600
LED Type SMD1010
Module Size(mm) 200×150×3
Viewing Angle H 160°, V 160°
Drive Method 1/32
Color Depth(nits) ≤800
Color Depth 16bit
Refresh Rate(Hz) ≥2800
Cabinet Cabinet Size(mm) 400×300×75
Cabinet Material die-casting aluminum
Cabinet weight(kg) 5.0kg
Electricity parameter Voltage 110/240V
Average.power(W / m2) 400
Max.power(W / m2) 1200
IP Grade IP31
Operating temperature/humidity temperature:-20ºC~ 50ºC humidity:10~90%RH
Storage temperature/humidity temperature:-40ºC~ 60ºC humidity:10~90%RH
Lifetime(h) ≥50000
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

FQA:
1. How can I place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer for the first
time. For designing or further discussion, it is better to contact us with Skype/email /phone, in case of any delays.

2. What kind of display we provide?
We have indoor/outdoor/rental taxi top /mobile LED display/LED stage/Irregular LED display for you to choose from.


3. Are you a manufacturer of led display. If yes, in which city?
Yes, Our factory with 2000 square meters. And we're in SHENZHEN city, GUANGDONG Province.

4. How long can I get the goods?
Our production time is about 10-25 working days. When you confirmed the order, we can start production
after receiving your deposit(30% TT in advance). we will update the production details in time.
we will notice you that we can deliver the goods to you after we get full payment.

Company Information:

Shenzhen LED World Co., Ltd was found in 2009, who specialized in the led field for nearly 10 years.
High quality and best competitive price at the market gained a good reputation from our clients.
Customer satisfaction is our prime objective and our high-quality LED video display screen used in more
than 140 countries and win a high reputation.
